DAF WWTP STP Wastewater Treatment Equipment

DAF WWTP STP wastewater treatment equipment is designed for industrial wastewater treatment plants, sewage treatment plants, commercial facilities, food processing factories, manufacturing facilities, and other applications requiring reliable solid-liquid separation and wastewater purification.

DAF stands for Dissolved Air Flotation, a widely used physicochemical separation technology for removing suspended solids, fats, oils, grease, and other floatable contaminants from wastewater. WWTP means Wastewater Treatment Plant, while STP commonly refers to Sewage Treatment Plant. These terms represent different levels of treatment-system scope, but they can be integrated into one complete wastewater treatment solution.

A modern wastewater treatment plant normally combines several processes rather than relying on a single machine. Depending on wastewater characteristics and discharge requirements, a treatment system may include screening, grit removal, equalization, pH adjustment, coagulation, flocculation, DAF, biological treatment, clarification, filtration, disinfection, sludge treatment, and water reuse.

What Is a DAF Wastewater Treatment System?

A Dissolved Air Flotation system separates suspended and floatable contaminants from wastewater using fine air bubbles.

In a typical DAF process, a portion of clarified water or treated recycle water is pressurized and saturated with air. When the pressurized water is released into the flotation tank, microscopic air bubbles form. These bubbles attach to suspended particles, oil droplets, grease, and suitable flocs, causing them to rise to the surface.

A mechanical skimmer then removes the floating sludge from the water surface, while clarified water flows from the flotation chamber toward subsequent treatment stages.

DAF is particularly useful for wastewater containing fine suspended solids, fats, oils, grease, and other low-density contaminants that may not separate efficiently through conventional gravity settling.

WWTP and STP Wastewater Treatment Equipment

A complete WWTP or STP is a combination of treatment processes designed to reduce pollutants before wastewater is discharged or reused.

A typical treatment train may include:

Inlet Screening → Equalization → pH Adjustment → Coagulation → Flocculation → DAF → Biological Treatment → Clarification → Filtration → Disinfection → Discharge or Reuse

The actual process should be selected according to wastewater quality, hydraulic loading, pollutant concentration, required effluent quality, and local regulatory requirements.

For industrial wastewater, additional processes may be required for specific pollutants. For example, high-strength organic wastewater may require anaerobic treatment, while wastewater with strict reuse requirements may require ultrafiltration, reverse osmosis, activated carbon, or advanced disinfection.

How DAF Works in Industrial Wastewater Treatment

The DAF process generally consists of several important stages.

1. Pressurization

A recycle stream is pressurized and mixed with air. Under pressure, air dissolves into the water.

2. Air Release

When the pressurized water enters the flotation tank through a pressure-release system, the dissolved air forms microscopic bubbles.

3. Bubble-Particle Contact

The bubbles attach to suspended solids, oil, grease, and chemically formed flocs.

4. Flotation

The bubble-particle aggregates become less dense than water and rise toward the surface.

5. Sludge Skimming

A surface scraper or skimmer continuously or intermittently removes the floating sludge.

6. Clarified Water Collection

The treated water is collected and sent to biological treatment, filtration, disinfection, or another downstream process.

The performance of DAF depends on wastewater characteristics, hydraulic loading, bubble generation, chemical dosing, particle properties, temperature, pH, and operating conditions. Therefore, actual treatment performance should be confirmed through wastewater testing and appropriate process design.

Main Applications

DAF WWTP and STP equipment can be customized for a wide range of wastewater treatment projects.

Food Processing Wastewater

Food processing wastewater may contain fats, oils, grease, proteins, suspended solids, and high concentrations of biodegradable organic matter. DAF can provide effective pretreatment before biological treatment.

Slaughterhouse Wastewater

Slaughterhouses and meat processing facilities may generate wastewater containing blood, fat, grease, meat particles, proteins, and suspended solids. DAF is often suitable for separating many of these contaminants.

Dairy Wastewater

Milk, cheese, butter, yogurt, and ice cream processing wastewater may contain milk fat, proteins, suspended solids, and organic matter. Flotation can help reduce FOG and solids loading.

Industrial Manufacturing Wastewater

Manufacturing wastewater may contain suspended solids, oils, metal particles, process chemicals, and other pollutants. The DAF system can be integrated with specialized treatment processes according to the wastewater composition.

Municipal and Commercial Sewage

STP systems can combine screening, biological treatment, clarification, filtration, and disinfection for domestic and commercial sewage.

Oil and Grease Wastewater

DAF is particularly suitable for wastewater containing dispersed oil and grease when the contaminants have appropriate flotation characteristics.

Coagulation and Flocculation

Coagulation and flocculation can be integrated before DAF when wastewater contains fine particles, colloids, or emulsified contaminants.

During coagulation, chemical agents destabilize particles. Flocculation then promotes controlled aggregation into larger flocs. These flocs can be more readily captured by air bubbles during flotation.

Chemical selection and dosing should not be standardized across all wastewater applications. Jar testing or pilot testing can help determine the appropriate chemical type, dosage, pH, and mixing conditions.

DAF as Pretreatment

One of the major applications of DAF equipment is wastewater pretreatment.

A DAF unit can be installed upstream of:

MBBR Systems
MBR Systems
SBR Systems
Activated Sludge Systems
Anaerobic Treatment
UF Systems
RO Systems
Advanced Filtration
Disinfection Systems

By removing suitable suspended and floatable contaminants before downstream treatment, DAF can help reduce the loading on biological reactors, membrane systems, pumps, and filtration equipment.

However, DAF is primarily a separation process. Dissolved biodegradable pollutants and other contaminants that do not readily attach to air bubbles may require biological, membrane, chemical, or advanced treatment.

Complete Industrial Wastewater Treatment Plant

A complete industrial WWTP can be designed around the customer's specific wastewater characteristics.

A customized process may include:

Coarse Screen → Fine Screen → Equalization Tank → pH Adjustment → Coagulation → Flocculation → DAF → MBBR/SBR/MBR → Secondary Clarifier → Sand Filter → Activated Carbon Filter → Disinfection → Reuse

For high-strength wastewater, anaerobic treatment can be incorporated to reduce organic loading before aerobic treatment.

For strict water reuse requirements, additional membrane processes such as UF, NF, or RO may be added after biological treatment and clarification.

Main Components of DAF Equipment

A complete DAF system may include:

DAF Flotation Tank
Recycle Water Pump
Air Compressor
Air Saturation Tank
Pressure Release Device
Dissolved Air System
Surface Sludge Skimmer
Sludge Collection System
Coagulation Tank
Flocculation Tank
Chemical Dosing System
Flow Meter
Pressure Gauges
Valves and Piping
Electrical Control Cabinet
PLC Automatic Control System

Equipment configuration can be modified according to flow capacity, wastewater composition, installation space, material requirements, and automation level.

Industrial Equipment Materials

DAF and wastewater treatment equipment can be manufactured using different materials depending on the project environment.

Common options include carbon steel, stainless steel, FRP, and other corrosion-resistant materials.

Stainless steel can be considered for applications requiring higher corrosion resistance or hygienic conditions. Carbon steel is commonly used for industrial structures where suitable coating or corrosion protection is specified. FRP can be considered for applications requiring lightweight and corrosion-resistant construction.

Material selection should be based on wastewater chemistry, operating temperature, chemical exposure, installation environment, and required service life.

Automatic Control System

Modern wastewater treatment equipment can be equipped with PLC control and an electrical control cabinet.

Automatic functions may include:

Pump Start and Stop
DAF Recycle Pump Control
Air Compressor Control
Chemical Dosing
Sludge Skimming
Sludge Discharge
Water Level Control
Flow Monitoring
Pressure Monitoring
High-Level Alarms
Equipment Protection

Optional remote monitoring and centralized control can also be incorporated into larger wastewater treatment plants.

Operation and Maintenance

Routine maintenance is important for reliable wastewater treatment performance.

Operators should regularly inspect the flotation tank, skimmer, recycle pump, air compressor, valves, chemical dosing system, pressure components, and sludge discharge system.

The DAF tank should be cleaned periodically to prevent excessive sludge accumulation. Chemical dosing should be monitored and adjusted when wastewater characteristics change.

For complete WWTP and STP systems, regular inspection of pumps, blowers, mixers, biological reactors, membranes, filters, and disinfection equipment is also required.

Customized Wastewater Treatment Solutions

Each wastewater treatment project has different requirements. Important design parameters include:

Average Flow Rate
Peak Flow Rate
COD
BOD
TSS
FOG
pH
Temperature
Ammonia Nitrogen
Total Nitrogen
Total Phosphorus
Salinity
Existing Treatment Equipment
Required Effluent Standard
Water Reuse Target
Available Installation Area

Based on these parameters, the appropriate DAF capacity, biological treatment process, filtration system, sludge treatment equipment, and control system can be selected.

Why Choose Us?

We provide DAF, WWTP, STP, and industrial wastewater treatment equipment for a wide range of commercial and industrial applications.

Our solutions can be supplied as individual DAF flotation units, packaged wastewater treatment systems, modular treatment plants, or complete customized wastewater treatment plants.

As an experienced wastewater treatment equipment manufacturer and supplier, we support customized tank dimensions, treatment capacity, construction materials, pumps, chemical dosing systems, PLC controls, piping, and complete process integration.

We can configure DAF with MBBR, SBR, MBR, activated sludge, filtration, disinfection, sludge treatment, and water reuse systems according to the customer's wastewater characteristics and project requirements.

OEM and customized industrial wastewater treatment equipment is available for international projects.

FAQ
1. What Does DAF Mean in Wastewater Treatment?

DAF means Dissolved Air Flotation. It is a flotation process that uses fine air bubbles to separate suitable suspended solids, oils, grease, and flocculated contaminants from wastewater.

2. What Does WWTP Mean?

WWTP means Wastewater Treatment Plant. It generally refers to a complete facility containing multiple wastewater treatment processes.

3. What Does STP Mean?

STP commonly means Sewage Treatment Plant. It is generally used for systems treating domestic or municipal-type sewage, although terminology can vary by region and project.

4. Can DAF Treat Industrial Wastewater?

Yes. DAF can be used for many industrial wastewater applications, especially wastewater containing suspended solids, oils, grease, and other floatable or flocculated contaminants.

5. Can DAF Be Used Before MBR?

Yes. DAF can be used as pretreatment before MBR when appropriate to reduce suspended solids, grease, and other contaminants that could increase downstream membrane loading.

6. Does DAF Remove COD and BOD?

DAF can reduce COD and BOD associated with suspended, colloidal, oily, and floatable material. Dissolved biodegradable COD and BOD generally require biological treatment.

7. Is Chemical Dosing Required?

Not necessarily. Chemical coagulation and flocculation may be added when improved removal of fine particles, colloids, or emulsified contaminants is required.

8. What Industries Use DAF Equipment?

Common applications include food processing, dairy, slaughterhouses, meat processing, poultry processing, oil and grease wastewater, manufacturing, chemical industries, and other industrial wastewater projects.

9. Can the WWTP Be Fully Automated?

Yes. PLC control can be configured for pumps, air systems, chemical dosing, skimmers, sludge discharge, alarms, and other equipment.

10. What Materials Are Available?

Carbon steel, stainless steel, FRP, and other suitable materials can be considered according to wastewater chemistry, corrosion requirements, and installation conditions.

11. How Is DAF Capacity Selected?

Capacity is selected based on average and peak wastewater flow, TSS, FOG, COD, BOD, temperature, pH, chemical requirements, treatment targets, and downstream processes.

12. Can You Supply a Complete STP or WWTP?

Yes. A complete system can integrate screening, equalization, DAF, biological treatment, clarification, filtration, disinfection, sludge treatment, and water reuse processes.

13. Can the Wastewater Treatment Equipment Be Customized?

Yes. Treatment capacity, tank dimensions, material, pump configuration, chemical dosing, automation, piping, flotation system, and complete process design can be customized.
