DAF Systems Dissolved Air Flotation Cells for Wastewater Treatment Daf Flotation Cells

Air flotation technology has been widely used in water supply, drainage and wastewater treatment in recent years. It can effectively remove the light floc which is difficult to precipitate in wastewater. With decades of technical experience accumulation and strong independent research and development ability, the company has devoted itself to developing a new type of air float, with stable effect, lower failure rate, easier operation and maintenance, and lower construction and operating costs.
2. Application
(1) Remove oil and TSS.
(2) Separate small particles and algae in groundwater.
(3) Recover valuable products in industrial sewage such as paper pulp.
(4) Act as secondary sedimentation tank to separate and concentrate suspended particles and sludge.
3. Features
(1) Large capacity, high efficiency and small occupying space.
(2) Compact structure, easy operation and maintenance.
(3) Silt expansion elimination.
(4) Aerate to the water while air floating, it has an obvious effect to the elimination of active agent and foul smell in water. Meanwhile, the increased dissolved oxygen provides a favorable condition to the follow-up process.
(5) It can achieve the best effect in adopting this method when disposing the water with lower temperature, lower turbidity and more algae.
Suitable area:
slaughtering, starch, pharmaceuticals, papermaking, printing and dyeing,
leather and tannery, petrochemical industry, domestic wastewater, etc.

DAF Systems Dissolved Air Flotation Cells for Wastewater Treatment DAF Flotation Cells

DAF Systems Dissolved Air Flotation Cells for Wastewater Treatment are designed for efficient solid-liquid separation in industrial, commercial, and process wastewater applications. Commonly known as dissolved air flotation systems or DAF flotation cells, these units use fine air bubbles to separate suspended solids, oil, grease, flocs, fibers, and other flotation-friendly contaminants from wastewater.

Dissolved air flotation is a well-established wastewater treatment technology. In a typical DAF process, air is dissolved into a pressurized water stream and then released into a flotation cell. The pressure reduction generates microscopic bubbles that attach to suspended particles and increase their buoyancy. The resulting float rises to the surface, where it can be removed by a mechanical scraper or skimming device.

DAF flotation cells can be installed as primary clarification equipment, wastewater pretreatment equipment, polishing units, or part of a larger industrial wastewater treatment plant.

How DAF Dissolved Air Flotation Cells Work

The DAF process generally begins with wastewater entering an equalization, mixing, or chemical pretreatment stage. Depending on the wastewater characteristics, coagulants and polymers can be added to destabilize fine particles and encourage floc formation.

A portion of the clarified effluent or another suitable water stream is pressurized and saturated with dissolved air. When this pressurized stream enters the flotation cell and pressure is reduced, dissolved air rapidly comes out of solution as numerous small bubbles.

The bubbles collide with and attach to suspended particles and flocs. As the bubble-particle aggregates rise, they form a floating layer at the water surface. A scraper or skimming mechanism moves the floating sludge toward a collection trough, while clarified water is collected separately.

EPA documentation describes both full-flow and recycle pressurization configurations. Recycle pressurization uses a portion of clarified effluent to generate the dissolved-air stream, which can reduce the amount of influent that must be pressurized.

Main Functions of DAF Flotation Cells

The primary function of a DAF flotation cell is rapid separation of contaminants that are suitable for flotation. Typical targets include:

Suspended solids
Fine suspended particles
Oil and grease
Floating solids
Fibers
Flocculated particles
Lightweight organic matter
Precipitated solids

DAF is especially useful for particles whose density is close to that of water and for oil and grease that are difficult to remove efficiently through conventional gravity sedimentation.

The actual removal performance depends on wastewater characteristics, particle size, surface chemistry, chemical conditioning, hydraulic loading, air-to-solids ratio, recycle flow, and DAF cell design.

DAF System Components

A complete DAF system can contain several integrated components. The exact configuration depends on the treatment capacity and wastewater application.

Pressurization Pump

The pressurization pump provides the pressure required to dissolve air into the recycle water or wastewater stream.

Air Injection System

Compressed air is introduced into the pressurized water stream. The air saturation system must provide stable conditions for generating fine bubbles after pressure release.

Retention or Saturation Tank

The retention tank provides sufficient contact time for air to dissolve into the pressurized water. EPA documentation identifies the retention tank as one of the conventional components of a DAF system.

Pressure Release System

A pressure-reducing valve or similar release device creates the rapid pressure drop needed to generate fine dissolved-air bubbles.

Flotation Cell

The flotation cell provides the environment where bubbles contact suspended particles and transport them toward the surface.

Surface Scraper

The scraper removes the floating sludge layer and transfers it to a collection trough or sludge outlet.

Clarified Water Outlet

Clarified water is collected separately from the flotation zone and discharged to downstream treatment or reuse processes.

Industrial Wastewater Treatment Applications

DAF systems can be used across many industries where suspended solids, oil, grease, or flotation-friendly flocs are present.

Food Processing Wastewater

Food-processing wastewater may contain fats, oils, grease, suspended organic solids, proteins, fibers, and other particulate matter. DAF can be used as a primary treatment or pretreatment stage before biological treatment.

Dairy Wastewater

Dairy wastewater may contain milk solids, fats, oils, grease, and suspended organic matter. DAF flotation cells can help reduce the solids and organic loading entering downstream processes.

Slaughterhouse Wastewater

Slaughterhouse and meat-processing wastewater often contains suspended solids, fats, oils, grease, and organic particles. DAF can provide an effective separation stage before biological or advanced treatment.

Paper and Pulp Wastewater

Paper and pulp processes can generate wastewater containing fibers, fillers, and fine suspended solids. DAF can assist with fiber and solids separation and process-water clarification.

Textile Wastewater

After appropriate coagulation and flocculation, DAF can separate suspended flocs and other particulate contaminants from textile and dyeing wastewater.

Chemical and Industrial Process Wastewater

Chemical wastewater can contain precipitated solids, suspended particles, oil, grease, and other contaminants. DAF can be integrated into physicochemical treatment systems when flotation is appropriate.

Oil-Containing Wastewater

DAF is particularly useful for separating dispersed oil, grease, and suspended solids from industrial wastewater. EPA documents identify DAF as a common technology for removing suspended solids and dispersed oil and grease.

DAF Pretreatment and Chemical Conditioning

Many DAF applications benefit from coagulation and flocculation before the flotation cell. Chemical conditioning can destabilize colloidal particles and combine small particles into larger flocs that are easier for air bubbles to capture.

Depending on wastewater chemistry, treatment systems may use aluminum-based or iron-based coagulants and polymers. Chemical selection should be based on actual wastewater characteristics rather than relying on a standard chemical recipe.

Jar testing or pilot testing can help determine appropriate chemical types, dosage, mixing conditions, and expected flotation performance.

DAF Cells for Efficient Solid-Liquid Separation

One of the major advantages of DAF is its ability to separate certain lightweight or poorly settling materials that may be difficult to remove using conventional sedimentation.

EPA technical information notes that DAF can be used when lighter suspended materials, oil, and grease require removal and can sometimes provide a more compact clarification footprint than conventional settling.

For industrial wastewater plants, DAF can therefore serve as a flexible treatment stage between screening and biological treatment, or between chemical precipitation and downstream filtration.

Automatic DAF System Control

Modern DAF systems can incorporate PLC-based automatic control for pumps, recycle flow, pressure regulation, chemical dosing, scraper operation, water level, and alarms.

Automation helps maintain stable operating conditions when wastewater flow and pollutant loading fluctuate. It can also reduce routine manual intervention and make process monitoring easier.

For larger projects, the DAF system can be integrated with equalization tanks, screening equipment, chemical dosing systems, biological treatment, membrane systems, filtration equipment, sludge dewatering machines, and reclaimed-water treatment processes.

Operation and Maintenance

Regular maintenance is essential for reliable DAF performance. Operators should inspect the recycle pump, air injection system, pressure components, valves, scraper mechanism, sludge collection trough, and chemical dosing equipment.

The flotation surface should be monitored regularly. Floating sludge should be removed at an appropriate frequency because excessive accumulation can disturb the flotation layer and potentially return captured particles to the water phase.

The pressure system should also be inspected according to the equipment manufacturer's operating and safety requirements.

System Selection Considerations

Selecting the correct DAF flotation cell requires more than matching the equipment to a nominal flow rate. Important factors include wastewater flow, peak flow, suspended solids concentration, oil and grease concentration, particle characteristics, temperature, pH, chemical requirements, sludge production, required effluent quality, and downstream treatment.

The flotation cell should be designed around the complete treatment process rather than operating as an isolated piece of equipment.

Why Choose Us?

DAF systems provide a practical solution for wastewater applications requiring efficient flotation-based clarification and solid-liquid separation.

The Dissolved Air Flotation Cells combine pressurized air dissolution, fine-bubble generation, particle flotation, surface sludge collection, and clarified-water separation within an integrated treatment process.

The system can be configured for industrial wastewater pretreatment, primary clarification, oil and grease separation, suspended solids removal, chemical wastewater treatment, food-processing wastewater, dairy wastewater, slaughterhouse wastewater, and other suitable applications.

With appropriate process design, chemical conditioning, automation, and sludge handling, DAF flotation cells can become an effective part of a complete wastewater treatment plant.

Frequently Asked Questions
1. What are DAF flotation cells?

DAF flotation cells are wastewater treatment chambers where dissolved-air bubbles attach to suspended particles and flocs, causing them to float to the surface for removal.

2. What does DAF stand for?

DAF stands for Dissolved Air Flotation, a flotation process that uses air dissolved under pressure and released to create fine bubbles.

3. What can DAF systems remove?

DAF can remove suspended solids, oil, grease, floating particles, fibers, and flocculated contaminants when the wastewater is suitable for flotation.

4. Are DAF systems suitable for industrial wastewater?

Yes. DAF is widely used in industrial wastewater treatment, particularly for streams containing suspended solids, oil, grease, and lightweight or poorly settling particles.

5. Do DAF flotation cells require chemicals?

Not every application requires chemicals, but coagulation and flocculation can significantly improve separation when fine or colloidal particles are difficult to float.

6. What is the difference between DAF and sedimentation?

Sedimentation relies primarily on gravity to make particles settle, while DAF uses fine air bubbles to make suitable particles and flocs rise to the surface.

7. Can DAF remove oil and grease?

Yes. DAF is commonly used to separate dispersed oil and grease along with suspended solids from industrial wastewater.

8. Can DAF be used for food wastewater?

Yes. DAF can be used for food-processing and dairy wastewater containing fats, oils, grease, suspended solids, and organic flocs.

9. What determines DAF cell capacity?

Flow rate, peak flow, wastewater characteristics, solids loading, oil and grease concentration, hydraulic loading, recycle flow, and treatment requirements all influence DAF sizing.

10. How is floating sludge removed?

A mechanical scraper or skimmer moves the floating sludge layer toward a collection trough, from which it is transferred to sludge handling equipment.

11. Can DAF systems be automated?

Yes. PLC controls can automate pumps, pressure systems, chemical dosing, scraper operation, alarms, and other process functions.

12. Can DAF cells be used before membrane treatment?

Yes. When appropriate for the wastewater, DAF can provide pretreatment before filtration, ultrafiltration, microfiltration, MBR, or other downstream processes.

13. How should a DAF system be selected?

The best configuration should be based on wastewater testing, flow rate, pollutant loading, flotation characteristics, treatment targets, available space, and the requirements of downstream treatment.
