Silicone Rubber Sheet, Silicone Rubber UV Resistance and Moderate Mesistance

Rubber Sheeting

We are able to offer various grades of rubber sheeting, these include:-
Neoprene
For general purpose gaskets and seals. Good UV resistance and moderate resistance to
oils and chemicals. Commercial grade 60°/70° sh. BS2752 grades from 40° to 70°.
Nitrile
Mainly used in an oil/fuel environment as it has excellent resistance. Commercial grade 60°/70° sh.
BS2751 40° to 70°
Natural
This material has excellent physical properties so is ideal for using as a seal in boats port
lights, hatches and doors. It has excellent abrasion resistance, so makes an ideal liner for shot blast
cabinets and material chutes. It is not resistant to oils. Hardness ranges from 40° to 70°
A food quality grade is available for marine fresh water tank seals.
Insertion
A natural rubber material with an insertion layer sandwiched in the middle of it to give it
strength, which helps prevent it tearing.
EPDM
This material has excellent resistance to UV, so is suitable for many outdoor applications. Commercial grade 60°/70°sh. A WRC grade is available for potable applications.

All of the above materials are available in ether full rolls, cut lengths, strip or gaskets.
Details and prices are available on application.
Our rubber sheet material is a general purpose industrial rubber used in any application needing a common elastic rubber material.  Used in all kinds of instances from decorative to rubber sheeting flooring runners, industrial buildings, OEM parts, and other agricultural situations.  This general purpose rubber sheet can be used almost anywhere that your applications need average rubber.  This general purpose rubber has a longer wear life because it is press cured when manufactured.

Silicone Rubber Sheet With UV Resistance And Moderate Resistance

Silicone rubber sheet is a flexible and versatile elastomeric material widely used for sealing, gasketing, insulation, cushioning, lining and protective applications. With good resistance to ultraviolet radiation, weathering and aging, silicone rubber sheets are suitable for indoor and outdoor industrial environments where long-term material stability is important. Silicone also offers useful resistance to many environmental conditions and chemicals, making it a practical choice for a broad range of industrial applications.

A silicone rubber sheet can be manufactured in different thicknesses, widths, lengths, hardness levels, surface finishes and colors to match specific application requirements. Depending on the formulation, silicone rubber may provide a combination of flexibility, temperature resistance, electrical insulation, weather resistance and moderate chemical resistance.

What Is Silicone Rubber Sheet?

Silicone rubber sheet is a flat rubber material manufactured from silicone elastomer compounds. Silicone polymers contain silicon and oxygen in their molecular structure, giving them different performance characteristics from conventional organic rubbers such as natural rubber, SBR and NBR.

The material can be supplied as smooth rubber sheet, textured rubber sheet, fabric-reinforced silicone sheet, sponge silicone sheet or custom-cut gasket material. For industrial applications, the appropriate formulation is selected according to temperature, chemical exposure, mechanical loading, environmental conditions and sealing requirements.

Silicone rubber sheet is particularly useful when UV exposure, outdoor weathering or temperature fluctuations are important considerations.

UV Resistance For Outdoor Applications

One of the major advantages of silicone rubber is its resistance to ultraviolet exposure and weathering. Outdoor equipment may experience sunlight, temperature changes, moisture and atmospheric exposure over extended periods. A suitable silicone rubber formulation can maintain useful flexibility and physical performance under these conditions.

This makes silicone sheet suitable for applications involving outdoor equipment, electrical enclosures, machinery components, seals, protective pads and industrial installations.

UV resistance should be considered together with the actual environment. Continuous sunlight exposure, ozone, temperature, chemicals and mechanical stress can affect service life differently, so material selection should be based on the complete operating condition.

Moderate Chemical Resistance

Silicone rubber provides resistance to many environmental substances and selected chemicals, but it should not be considered universally chemical-proof. Compatibility depends on the silicone formulation, chemical concentration, temperature, exposure time and mechanical conditions.

For applications involving aggressive acids, solvents, fuels, oils or specialized chemicals, compatibility testing or technical confirmation is recommended before production.

If strong oil or fuel resistance is the primary requirement, NBR or another specialized elastomer may be more appropriate depending on the application. Silicone is generally selected when flexibility, temperature performance, weather resistance and electrical insulation are more important.

Key Features Of Silicone Rubber Sheet

Silicone rubber sheets can provide several useful characteristics for industrial users:

Good UV and weather resistance
Good resistance to aging and ozone exposure
Flexible and resilient material structure
Useful temperature resistance depending on formulation
Good electrical insulation properties
Low moisture absorption in many applications
Smooth and easy-to-clean surface options
Suitable for indoor and outdoor applications
Available in different hardness levels
Easy to die cut, punch, slit or fabricate
Suitable for custom gaskets and sealing components
Available in custom dimensions and colors

The actual performance of a silicone sheet depends on the specific compound and manufacturing specification.

Industrial Applications

Silicone rubber sheet is used in many industries where flexibility, environmental resistance and sealing performance are required.

Common applications include:

Sealing And Gasketing

Silicone sheet can be die-cut or fabricated into gaskets, washers, seals and custom sealing components for machinery, equipment and enclosures.

Electrical And Electronic Equipment

Silicone is commonly considered for electrical insulation, protective pads, insulating components and sealing applications because of its electrical insulation characteristics.

Outdoor Equipment

Its UV and weather resistance makes silicone sheet suitable for selected outdoor machinery, equipment housings, seals and protective components.

Machinery And Equipment

Silicone rubber sheets can be used as cushioning pads, protective layers, seals, vibration-isolation components and equipment interfaces.

Food And Processing Equipment

Certain silicone compounds are available for applications where specific regulatory or food-contact requirements apply. The exact grade should always be confirmed for the intended application rather than assuming every silicone sheet is suitable for food contact.

HVAC And Industrial Systems

Silicone sheet can be fabricated into gaskets and sealing components for selected HVAC, thermal and industrial equipment applications.

Silicone Rubber Sheet Vs Other Rubber Sheets

Different rubber materials provide different performance characteristics.

NBR rubber sheet is often considered where resistance to petroleum oils and fuels is important. EPDM rubber sheet is widely used for weather, ozone, water and outdoor applications. Neoprene provides a balanced combination of environmental and mechanical properties. SBR is commonly used for general-purpose rubber applications.

Silicone stands out when UV resistance, weathering, flexibility, temperature performance and electrical insulation are important.

Therefore, choosing a silicone rubber sheet should be based on the actual working environment rather than simply selecting the material with the broadest list of properties.

How To Select The Right Silicone Rubber Sheet

Before purchasing silicone sheet, consider:

Thickness: Select the thickness according to sealing, insulation, cushioning or protective requirements.

Width And Length: Sheet dimensions should match the available installation area and fabrication process.

Hardness: Different hardness levels can be supplied depending on flexibility, compression and mechanical requirements.

Temperature: Confirm the actual continuous and intermittent operating temperatures with the supplier.

Chemical Exposure: Identify all liquids, gases, cleaning agents and chemicals that may contact the material.

UV And Weather Exposure: For outdoor applications, confirm that the selected compound is appropriate for long-term environmental exposure.

Surface Finish: Smooth, textured or customized surfaces can be selected according to the application.

Color: Silicone sheets can be supplied in different colors depending on formulation and production requirements.

Reinforcement: Fabric reinforcement can be considered where additional dimensional stability or mechanical support is required.

Custom Silicone Rubber Sheet Manufacturing

A professional silicone rubber sheet manufacturer can customize material construction according to application requirements. Custom options may include thickness, width, length, hardness, color, surface finish, reinforcement and die-cut shapes.

For gasket production, the silicone sheet can be supplied as rolls or flat sheets and then converted into finished components. Custom cutting can help reduce material waste and simplify assembly.

OEM and ODM production can also be considered for customers requiring private-label products, special dimensions or application-specific rubber compounds.

Installation And Maintenance

Before installation, make sure the mating surfaces are clean, dry and free from sharp edges or contaminants. The silicone sheet should be stored away from unnecessary heat, direct sunlight, ozone-generating equipment and substances that may adversely affect the material.

When using silicone as a gasket, avoid excessive compression or uneven tightening. The installation method should follow the equipment manufacturer's requirements and the design of the sealing system.

Periodic inspection can identify compression damage, cuts, swelling, surface deterioration or other changes that may affect performance.

Why Choose Us

As an experienced silicone rubber sheet manufacturer and supplier, we focus on providing material solutions for industrial sealing, insulation, cushioning and protection applications.

Application-Based Material Selection: We help match silicone formulations with operating conditions.
Custom Sizes: Sheet thickness, width and length can be customized.
Multiple Hardness Options: Material hardness can be selected according to application requirements.
Custom Colors: Different colors are available for suitable silicone formulations.
Surface Options: Smooth and customized surface finishes can be discussed.
OEM & ODM Support: Custom production is available for industrial buyers and distributors.
Flexible Order Support: We can support different purchasing requirements depending on production conditions.
Export Experience: Products can be prepared for international B2B customers and industrial projects.

Whether you need silicone rubber sheet for gaskets, electrical insulation, outdoor equipment, machinery or custom industrial components, we can help identify a suitable material specification.

FAQs
1. What Is Silicone Rubber Sheet Used For?

Silicone rubber sheet is commonly used for gaskets, seals, insulation, cushioning, protective pads, equipment interfaces and selected lining applications.

2. Is Silicone Rubber Sheet UV Resistant?

Silicone rubber generally has good resistance to UV radiation and weathering, making suitable formulations useful for many outdoor applications.

3. Does Silicone Rubber Have Chemical Resistance?

Silicone provides resistance to many environmental substances and selected chemicals. However, chemical compatibility depends on the formulation and operating conditions.

4. Is Silicone Rubber Sheet Suitable For Outdoor Use?

Yes. Its UV, ozone and weather resistance can make silicone suitable for many outdoor sealing and protection applications.

5. Is Silicone Rubber Sheet Oil Resistant?

Silicone should not automatically be selected for petroleum oil or fuel exposure. NBR and other specialized compounds may be more appropriate depending on the specific oil and temperature.

6. Can Silicone Rubber Sheet Be Used For Gaskets?

Yes. Silicone sheet can be die-cut, punched or fabricated into many types of gaskets and sealing components.

7. Can You Supply Custom Silicone Rubber Sheets?

Yes. Custom thickness, dimensions, hardness, color, surface finish and reinforcement options can be discussed according to the application.

8. Is Silicone Rubber Electrically Insulating?

Silicone rubber generally has useful electrical insulation properties and is used in selected electrical and electronic applications. The exact electrical specification depends on the compound.

9. How Do I Choose Silicone Sheet Thickness?

Thickness should be selected according to the required sealing, insulation, cushioning, compression and mechanical conditions of the application.

10. Can You Provide OEM Silicone Rubber Sheet?

Yes. OEM and ODM production can be arranged for industrial customers requiring customized dimensions, formulations, colors, packaging or fabricated components.
