Diesel Engine Mini Power Tiller Technical Parameters

Diesel Engine Mini Power Tiller can be equipped with lamp, water pump, ridge, sprayer, trailer, furrow plough, seeder, fertilizer distributor.

Farm Machinery Gasoline/Diesel Engine Walking Tractor Motocultor Rotary Tiller Mini Power Tiller Power Weeder Mini Cultivator Agricultural Machinery,This series power tiller can be equipped with lamp, water pump, ridge, sprayer, trailer, furrow plough, seeder, fertilizer distributor. etc. Well perform between mountain and hilly farmland, dry and paddy field, orchard, vegetable greenhouse, potato land, corn land and coco land, sand land etc.
Product name 170 Gasoline Tiller   177 Gasoline Tiller   182 Gasoline Tiller   173 Diesel Tiller   178 Diesel Tiller   186 Diesel Tiller
Structure Type Forced air-cooled, four-stroke, swashplate, single-cylinder Forced air-cooled, four-stroke, swashplate, single-cylinder Forced air-cooled, four-stroke, swashplate, single-cylinder Forced air-cooled, four-stroke, swashplate, single-cylinder Forced air-cooled, four-stroke, swashplate, single-cylinder Forced air-cooled, four-stroke, swashplate, single-cylinder
Nominal Power 4 kW 4.5 kW 6.5 kW 4.05 kW 4 kW 6.5 kW
Overall dimension(mm) 1680x1000x800 mm 1680x1000x800 mm 1580x1010x950 mm 1580x1000x800 mm 1700x1050x800 mm 1470x1350x800 mm
Weights 70kg 90kg 100kg 100kg 100kg 100kg
Transmission mode Gear Gear Gear Gear Gear Gear
Connection mode Direct connection Direct connection Direct connection Direct connection Direct connection Direct connection
speed Fast gear F:127 r/min
Slow gear S:83 r/min
Fast gear F:145 r/min
Slow gear S:83 r/min
Fast gear F:145 r/min
Slow gear S:83 r/min
Fast gear F:130 r/min
Slow gear S:93 r/min
Fast gear F:146 r/min
Slow gear S:93 r/min
Fast gear F:146 r/min
Slow gear S:93 r/min
Ploughing width 1000 mm 1050 mm 1350 mm 1000 mm 1050 mm 1350 mm
Ploughing depth ≥100 mm ≥100 mm ≥100 mm ≥100 mm ≥100 mm ≥100 mm
Working speed 0.1~0.3 m/s 0.1~0.3 m/s 0.1~0.3 m/s 0.1~0.3 m/s 0.1~0.3 m/s 0.1~0.3 m/s
Hourly productivity ≥0.04  hm² ≥0.04  hm² ≥0.04  hm² ≥0.04  hm² ≥0.04  hm² ≥0.04  hm²
Fuel consumption per unit of working area ≤35 kg/hm ² ≤35 kg/hm ² ≤35 kg/hm ² ≤30 kg/hm ² ≤30 kg/hm ² ≤30 kg/hm ²
