Hydraulic Horizontal Metal Pins Riveting Machine SS MS Long Solid Rivets Buttoning Riveter Hinge Fasteners Setting Tool

Model	143D
Rivet ability	Solid Φ2-8mm
Throat depth	125mm
Motor	2HP
Most tremendous pressure	200-1100kg
Mechanical altitude	50-300mm
Working area	190*320mm
Net weight	300kg

1. The machine has small size, no noise, high efficiency, and is suitable for assembly line operation.
2. High accuracy, suitable for riveting processing of small parts, less air consumption,
3. The pressure, stroke, speed and riveting time are all adjustable.
4. According to customer's product requirements, the height, shape, throat depth and stroke of the body can be specially
customized

Hydraulic Horizontal Metal Pins Riveting Machine

The Hydraulic Horizontal Metal Pins Riveting Machine is an industrial fastening solution designed for applications involving metal pins, long solid rivets, hinges, buttons, fasteners, and other mechanical components. Its horizontal hydraulic riveting configuration provides a practical solution for workpieces that require side-access riveting, long rivet installation, or controlled fastening of metal components.

Horizontal riveting equipment can be especially useful when the workpiece geometry makes conventional vertical riveting difficult. By positioning the riveting head horizontally, operators can access specific fastening locations while maintaining a stable workpiece position.

The machine can be configured for compatible stainless steel (SS), mild steel (MS), and other metal components according to the actual rivet specifications, workpiece dimensions, and tooling requirements.

Horizontal Hydraulic Riveting System

The hydraulic drive system provides controlled mechanical force for riveting and fastener-setting operations. Hydraulic power is well suited to industrial applications where repeatable force application is important.

The horizontal configuration allows the riveting tool to approach the workpiece from the side. This can be beneficial for long components, hinges, brackets, profiles, frames, and assemblies where vertical access is limited.

The actual riveting force, compatible rivet dimensions, operating cycle, and working range depend on the machine configuration and selected tooling. Customers should evaluate the machine using their actual workpieces and rivets before establishing production parameters.

Long Solid Rivet Installation

Long solid rivets can present different challenges compared with standard short rivets. Their length, diameter, material, and workpiece structure all influence the required riveting process.

The machine is designed to provide a controlled setting process for compatible long solid rivets. Appropriate dies and riveting tools can help maintain alignment while forming the rivet securely.

Long solid rivet applications may include:

Metal hinges
Industrial brackets
Mechanical joints
Metal frames
Hardware assemblies
Machinery components
Structural fittings
Heavy-duty fasteners
Metal profiles
Industrial hardware

The final tooling configuration should be selected according to the actual rivet dimensions and workpiece geometry.

Metal Pin Riveting

Metal pins can be used in a variety of mechanical assemblies where components need to be connected, aligned, or mechanically secured.

A hydraulic metal pin riveting machine can support repetitive pin-setting and riveting operations while reducing the physical effort required from operators.

For production environments, controlled riveting can also help improve consistency between individual assemblies. Proper alignment between the pin, workpiece, and riveting tool is important for achieving a reliable finished connection.

Depending on the application, the machine may be used for metal pin installation, solid rivet forming, hinge fastening, and other compatible mechanical fastening processes.

SS and MS Riveting Applications

The machine can be evaluated for SS and MS riveting applications.

Stainless steel is commonly selected for components requiring corrosion resistance and durability, while mild steel is widely used in industrial fabrication, machinery, hardware, construction components, and general metal manufacturing.

Different materials have different forming characteristics. Therefore, the machine's hydraulic force, die design, riveting head, and workpiece fixture should be matched to the specific material and rivet.

Manufacturers should provide information about the metal grade, rivet dimensions, and component thickness when selecting the appropriate configuration.

Hinge Riveting and Fastener Setting

Hinge assembly is one of the practical applications for horizontal riveting equipment. Hinges often contain narrow or recessed fastening positions where access can be difficult with a conventional vertical machine.

The horizontal structure allows the riveting head to approach the hinge from the appropriate direction. Customized fixtures can be used to support the hinge and connected components during the riveting process.

Potential hinge-related applications include:

Metal hinges
Furniture hinges
Industrial hinges
Machinery hinges
Cabinet hardware
Door hardware
Folding mechanisms
Mechanical joints
Industrial fasteners

The exact application depends on the hinge structure, rivet dimensions, and required finished joint.

Buttoning and Fastener Setting

The machine can also be considered for compatible buttoning and fastener-setting applications involving metal components.

Depending on the tooling configuration, setting tools can be designed for particular fasteners, pins, rivets, or button-style hardware. This flexibility allows manufacturers to evaluate the same basic machine platform for different fastening operations.

For custom production, interchangeable dies and fixtures may help manufacturers process different products without completely replacing the machine.

Stable Workpiece Positioning

Workpiece positioning plays an important role in horizontal riveting. Because the riveting force is applied from the side, the component should be securely supported during the cycle.

Customized fixtures can be designed around the shape of the workpiece. A suitable fixture can help prevent movement, maintain rivet alignment, and reduce operator positioning variation.

For repetitive production, dedicated fixtures can also improve loading and unloading efficiency.

Controlled Riveting Quality

A reliable riveting process requires the correct combination of hydraulic force, rivet dimensions, die geometry, hole size, and workpiece material.

The hydraulic system provides controlled force during the setting process, while the riveting tooling determines how the rivet or pin is formed.

With appropriate machine parameters and tooling, manufacturers can achieve more consistent fastening results than with purely manual riveting methods.

For critical industrial applications, finished joints should be inspected and validated according to the customer's internal quality requirements.

Industrial Metal Fastening

The machine is suitable for manufacturers that require a reliable solution for repetitive metal fastening operations. It can be used in metal fabrication, hardware manufacturing, machinery assembly, construction component production, and other industrial applications.

Potential workpieces include steel brackets, stainless steel components, metal profiles, hinges, frames, panels, mechanical assemblies, and other compatible products.

Its horizontal configuration can provide additional flexibility when working with long or geometrically complex components.

Flexible Tooling and Setting Dies

Different rivets and fasteners require different tooling. A machine intended for long solid rivets may require different dies from one used for short rivets or button-style fasteners.

Tooling can be evaluated or customized according to:

Rivet diameter
Rivet length
Rivet material
Pin dimensions
Workpiece thickness
Fastener shape
Riveting position
Product geometry
Required joint configuration

Customized tooling helps manufacturers create a more application-specific production process.

Improve Production Efficiency

Manual riveting and pin setting can become labor-intensive when large quantities of components need to be processed.

A hydraulic machine can standardize repetitive riveting operations and reduce the physical effort required from operators. With dedicated fixtures, the operator can position the workpiece, perform the hydraulic riveting cycle, and repeat the process efficiently.

For higher-volume manufacturing, the equipment can also be evaluated for integration with feeding, positioning, inspection, and other production processes.

OEM and Custom Manufacturing

The Hydraulic Horizontal Metal Pins Riveting Machine is suitable for OEM manufacturers, hardware suppliers, machinery producers, hinge manufacturers, metal fabricators, and industrial component manufacturers.

Machine configuration can be evaluated according to the customer's actual product requirements, including:

Workpiece dimensions
Rivet and pin specifications
Material type
Riveting location
Required production volume
Tooling requirements
Fixture design
Automation requirements

Customers can provide product drawings, samples, photographs, and rivet samples for application evaluation.

Why Choose Our Hydraulic Horizontal Riveting Machine?
1. Horizontal Riveting Configuration

Provides side-access riveting for components where vertical access is inconvenient.

2. Hydraulic Driving

Offers controlled force application for repetitive industrial fastening operations.

3. Long Solid Rivet Applications

Suitable for compatible long solid rivets, metal pins, and industrial fasteners.

4. SS and MS Compatibility

Can be evaluated for stainless steel and mild steel components according to tooling requirements.

5. Hinge Fastener Setting

Suitable for compatible hinge, bracket, and mechanical joint applications.

6. Flexible Tooling

Riveting dies and setting tools can be configured for different rivets and fasteners.

7. Stable Workpiece Positioning

Customized fixtures can improve alignment and production consistency.

8. OEM Customization

Suitable for customized industrial riveting and fastener-setting projects.

Main Applications

The machine can be used for:

Long Solid Rivet Installation
Metal Pin Riveting
Hinge Riveting
Hinge Fastener Setting
Stainless Steel Riveting
Mild Steel Riveting
Metal Button Setting
Industrial Hardware Assembly
Metal Bracket Riveting
Machinery Component Riveting
Metal Frame Assembly
Construction Hardware
General Metal Fastening
How to Choose the Right Horizontal Riveting Machine?

When selecting a hydraulic horizontal riveter, manufacturers should consider the rivet or pin material, diameter, length, workpiece material, component thickness, riveting position, and required production volume.

For long solid rivets, the available working space and tooling geometry are particularly important. The horizontal riveting head should have suitable access to the fastening location without interfering with the workpiece.

Manufacturers should also consider whether they require a standard riveting tool, customized die, dedicated fixture, interchangeable tooling, or a more automated production setup.

For an accurate quotation, provide product drawings or samples, rivet and pin specifications, material information, fastening locations, production quantity, and any existing production requirements.

FAQS
Q1: What is a horizontal hydraulic riveting machine?

A horizontal hydraulic riveting machine applies controlled hydraulic riveting force from a horizontal direction, making it suitable for components requiring side-access fastening.

Q2: Can this machine install long solid rivets?

Yes. It can be evaluated for compatible long solid rivets based on rivet length, diameter, material, and workpiece configuration.

Q3: Can it rivet stainless steel and mild steel?

Yes. SS and MS applications can be considered when the machine and tooling are correctly matched to the material and rivet specifications.

Q4: Can the machine be used for hinges?

Yes. Hinge riveting and hinge fastener-setting are suitable applications when the workpiece dimensions and rivet specifications match the machine configuration.

Q5: What are metal pins used for?

Metal pins can be used to connect, align, or mechanically secure components in machinery, hardware, hinges, and other mechanical assemblies.

Q6: Can the tooling be customized?

Yes. Riveting dies, setting tools, workpiece fixtures, and other tooling can be customized or selected according to the customer's product.

Q7: Can it perform buttoning operations?

Compatible button-style metal fasteners can be considered with suitable setting tooling. The exact process should be evaluated based on the fastener design.

Q8: Is hydraulic riveting suitable for industrial production?

Yes. Hydraulic riveting is commonly considered for repetitive industrial fastening where controlled mechanical force and consistent operation are required.

Q9: Can one machine handle different rivets?

Different tooling configurations may allow different rivet types or sizes to be processed. The compatible range depends on the machine and tooling configuration.

Q10: What information should I provide for a customized machine?

Provide workpiece drawings or samples, rivet or pin dimensions, material type, component thickness, fastening position, production volume, and desired tooling or automation requirements.
