Electric Hats Caps Shoes Eyelet Punching Machine 3mm 4mm 5mm Rivets Eyeleter Eyelets Puncher and Riveter

1 Structure characteristics:
Suitable for nailing and riveting the nail eye of midsole, paper box, leather, paper bag, gift box, label, punched belt, leather
parts, etc. Simple operation, reliable performance. High efficiency.

Widely used in handbag, carton lifting ring production, file bag, document bag pressure ring production, confidential document,
ordinary document binding, card anti-counterfeiting binding, hangtag hole ring production, anti-counterfeiting packaging box
sealing bag, clothing shoes and hats, leather products, luggage mattress air hole eyelet buckle production, etc.;

2 Features：
With two working heads, riveting at the same time
(1): Automatically feed rivets;
(2) Accurate positioning of perforation and good nailing effect;
(3): Distance between two ends can be adjusted, rivet at the same time, which greatly improves the work efficiency;
(4): Operation is simple and convenient, which greatly improves the production efficiency;ni Excavator delivers power and performance in a compact size to help you work in the tightest applications. Its ability to fit through a narrow doorway makes it an excellent machine for indoor demolition work

Machine model	Electric Eyelets riveting machine
Model	168
Throat depth	200mm
Product capacity	195pieces/ minutes
Rivet diameter	3-12mm
Rivet length	2-10mm
Voltage	Single phase
Power	0.37kw
Size	680X350x1400mm
Weight	120kg
Usage	Garment hangtags,Carrying lis,File bag,Leather,Luggage

Electric Eyelet Punching and Riveting Machine

The Electric Eyelet Punching Machine is a practical industrial solution for punching holes and installing eyelets in hats, caps, shoes, bags, leather goods, apparel, textiles, and other compatible products. Designed as an eyelet puncher and riveter, the machine combines hole preparation and eyelet setting functions to help manufacturers achieve a more efficient and consistent fastening process.

Eyelets are widely used in footwear, headwear, bags, clothing, leather products, promotional goods, sports equipment, and accessories. They provide reinforced openings for laces, cords, straps, drawstrings, ventilation, decoration, and other functional purposes.

The machine can be configured for compatible 3mm, 4mm, and 5mm eyelets according to the selected tooling, die, punch, and eyelet design. The actual compatible eyelet range should be confirmed based on the specific machine configuration and customer application.

Electric Eyelet Punching System

The electric drive system provides powered operation for repetitive eyelet punching and setting tasks. Compared with manual hand tools, an electric eyelet machine can reduce operator effort and support a more consistent production workflow.

The punching process creates or prepares an opening in the workpiece before the eyelet is inserted. Proper hole positioning is important because the hole diameter and location need to correspond with the eyelet and final product design.

A suitable punch and die can be selected according to the required eyelet size and material. For production involving multiple eyelet sizes, interchangeable tooling may provide additional flexibility.

Eyelet Puncher and Riveter

The combination of eyelet puncher and riveter functions makes the machine useful for production processes where the material needs to be punched and then fitted with an eyelet.

A typical process may include:

Positioning the workpiece.
Aligning the required eyelet location.
Punching the hole.
Placing the eyelet.
Forming or setting the eyelet.
Checking the finished eyelet connection.

The exact operating sequence depends on the machine configuration and tooling arrangement.

This integrated approach can help reduce repetitive manual operations and provide a more organized workflow for industrial eyelet installation.

3mm, 4mm and 5mm Eyelet Applications

The machine is designed around common small eyelet sizes such as 3mm, 4mm, and 5mm, subject to the selected tooling.

Different eyelet diameters are suitable for different product requirements. Smaller eyelets may be used for lightweight apparel, accessories, and decorative applications, while larger eyelets may be preferred for lacing, cords, straps, and applications requiring a larger opening.

The correct punch and setting die should match the actual eyelet dimensions. Manufacturers producing multiple eyelet sizes can consider interchangeable tooling to support different product designs.

Hat and Cap Eyelet Machine

Eyelets are frequently used in hats and caps for ventilation, decoration, or functional openings. The machine can be considered for compatible headwear products where small metal eyelets need to be installed accurately.

For hat and cap production, positioning is particularly important because the workpiece may have curved surfaces or limited working space.

Suitable fixtures can help stabilize the cap or hat during punching and eyelet setting. Customized positioning tooling may be considered for specific headwear designs.

Potential applications include:

Baseball caps
Fashion hats
Sports caps
Work caps
Outdoor headwear
Promotional caps
Uniform headwear
Textile accessories
Shoe and Footwear Eyelet Riveting

Footwear is another important application for eyelet installation. Shoes, boots, sneakers, work footwear, and other products may use eyelets for lacing systems or decorative details.

An electric shoe eyelet machine can help manufacturers perform repetitive punching and eyelet setting operations with improved consistency.

Depending on the footwear design, customized fixtures can help position the upper material correctly before the eyelet is installed.

The appropriate tooling should be selected according to the shoe material, eyelet dimensions, hole pattern, and finished appearance requirements.

Bag and Leather Eyelet Applications

Bags, leather goods, backpacks, handbags, luggage, tool bags, and other accessories may require eyelets for handles, cords, straps, ventilation, or decorative purposes.

The machine can be used for compatible leather, synthetic leather, textile, canvas, and other materials.

Because different materials have different thicknesses and physical characteristics, the punch, die, and eyelet-setting process should be matched to the specific product.

For high-volume bag production, a dedicated fixture can help improve workpiece positioning and production efficiency.

Apparel and Textile Eyelet Setting

Eyelets and grommets are also used in apparel and textile products. Applications may include drawstring openings, decorative details, sportswear, uniforms, outdoor clothing, and functional textile components.

The machine provides a powered alternative to manual eyelet installation and can support repetitive production operations.

For delicate fabrics, the punching and setting process should be carefully matched to the material to reduce deformation or unnecessary damage around the eyelet.

Consistent Eyelet Positioning

Eyelet quality depends not only on the setting process but also on accurate hole positioning. A poorly positioned hole can affect the appearance, function, and overall quality of the finished product.

A suitable workpiece fixture can help operators maintain consistent positioning during repeated cycles.

For OEM manufacturing, custom fixtures can be designed around the product geometry. This is especially useful for curved hats, shoes, bags, and other products where conventional flat workpiece positioning may be difficult.

Eyelet Setting Quality

Proper eyelet forming creates a secure connection between the eyelet and the material. The final result depends on eyelet material, eyelet dimensions, workpiece material, hole diameter, punch geometry, setting die, and machine parameters.

The electric eyelet riveting machine provides a controlled mechanical process for repetitive setting operations.

Manufacturers should test the actual eyelet and material combination before mass production to determine the appropriate tooling and operating conditions.

Flexible Tooling

Different eyelet sizes require corresponding punches and dies. The machine can therefore be configured with application-specific tooling.

Potential tooling configurations include:

3mm Eyelet Punch
4mm Eyelet Punch
5mm Eyelet Punch
Eyelet Setting Dies
Punching Dies
Riveting Dies
Product Fixtures
Positioning Tools
Interchangeable Tooling

Customized tooling can be evaluated according to the customer's eyelet dimensions and product structure.

Improve Production Efficiency

Manual eyelet installation can become slow and physically demanding when production volumes increase. Operators may need to punch holes and install individual eyelets repeatedly throughout the production process.

Electric eyelet equipment can help standardize these repetitive operations and reduce manual effort.

For batch production, a dedicated machine can also help improve production organization and reduce variation between operators.

OEM and Custom Eyelet Solutions

The machine is suitable for manufacturers producing hats, caps, footwear, bags, leather goods, apparel, textile products, and accessories.

OEM and custom machine configurations can be evaluated based on:

Eyelet diameter
Eyelet material
Workpiece material
Product thickness
Hole diameter
Eyelet location
Product geometry
Production volume
Required tooling
Desired automation level

Customers can provide samples, drawings, eyelet samples, and product photographs to help determine a suitable configuration.

Why Choose Our Electric Eyelet Punching Machine?
1. Electric Powered Operation

Provides convenient powered operation for repetitive eyelet punching and setting.

2. Punching and Riveting Functions

Combines hole punching and eyelet setting operations in one practical production solution.

3. Multiple Eyelet Sizes

Can be configured for compatible 3mm, 4mm, and 5mm eyelets with suitable tooling.

4. Wide Product Applications

Suitable for hats, caps, shoes, bags, leather goods, apparel, and textile products.

5. Consistent Eyelet Installation

Controlled machine operation helps improve repeatability during batch production.

6. Flexible Tooling

Punches, dies, and fixtures can be selected according to different eyelet and product requirements.

7. Production Efficiency

Reduces repetitive manual operations and supports a more efficient production workflow.

8. OEM Customization

Suitable for customized eyelet punching, setting, and riveting applications.

Main Applications

The machine can be used for:

Hat Eyelet Installation
Cap Eyelet Installation
Shoe Eyelet Riveting
Boot Eyelet Setting
Bag Eyelet Installation
Leather Eyelet Riveting
Apparel Eyelet Setting
Textile Eyelet Installation
Canvas Eyelet Riveting
Backpack Eyelet Machine
Luggage Eyelet Installation
Fashion Accessory Eyelet Setting
Promotional Product Eyelet Installation
How to Choose the Right Eyelet Punching Machine?

When selecting an electric eyelet puncher and riveter, manufacturers should consider the eyelet diameter, eyelet material, workpiece material, material thickness, hole size, product shape, and required production volume.

If you need to process 3mm, 4mm, and 5mm eyelets, confirm whether interchangeable punches and dies are available for the required sizes.

For curved products such as hats, caps, and shoes, fixture design is also important because the workpiece must remain stable during punching and setting.

For a customized quotation, customers should provide eyelet samples, product samples or drawings, material information, eyelet dimensions, and expected production quantity.

FAQS
Q1: What is an electric eyelet punching machine?

An electric eyelet punching machine is powered equipment used to punch holes and install eyelets in compatible materials such as fabric, leather, canvas, and footwear materials.

Q2: Can it punch and install eyelets?

Yes. It is designed as an eyelet puncher and riveter for applications requiring both hole punching and eyelet setting.

Q3: Can it work with 3mm, 4mm, and 5mm eyelets?

The machine can be configured for compatible 3mm, 4mm, and 5mm eyelets using suitable punches and setting dies. Exact compatibility should be confirmed according to the tooling configuration.

Q4: Can this machine be used for hats and caps?

Yes. It can be considered for compatible hats, baseball caps, sports caps, work caps, and other headwear products.

Q5: Can it be used for shoes?

Yes. Shoe and footwear eyelet installation is one of the main potential applications.

Q6: Can it process leather?

It can be used for compatible leather and synthetic leather applications. The tooling and punching process should match the leather thickness and eyelet specifications.

Q7: Can the tooling be changed for different eyelet sizes?

Interchangeable tooling can be considered for different eyelet sizes. The available configuration depends on the specific machine.

Q8: What products can use this eyelet machine?

Typical applications include hats, caps, shoes, boots, bags, backpacks, luggage, leather goods, apparel, canvas products, and textile accessories.

Q9: Can the machine be customized?

Yes. Punches, dies, fixtures, positioning tools, and other components can be evaluated according to the customer's product and eyelet requirements.

Q10: What information should I provide for a quotation?

Please provide the eyelet size and material, product sample or drawing, workpiece material and thickness, hole dimensions, eyelet position, production quantity, and any special tooling requirements.
