Full Automatic Round Pipe Punching Small Holes Tube Punch and Cut Down Machine Technical Parameters

Full automatic round pipe punching and cutting machine for small hole punching, tube positioning, and automatic cutting of metal pipes and round tubes..

1 Intelligent operating system, cut corner bending, different angles are optional
2 Feeding length 3 and 6 m, can be customized
3 The distance between the angles of attack can be set
4 Diversified functions, angle cutting, punching hole, cutting down, arc punching, pipe end punching
Should have areas: furniture. guardrails. shelves. building climbing frames

Model 8TA 8TB 15TA 15TB 20TA 20TB
Feed length 3000 6000 3000 6000 3000 6000
Nominal force 80kn 150kn 250kn
Stroke 100mm 120mm 150mm
Motor power 4kw 5.5kw 7.5kw
Punching capacity(metal thickness) ≤2mm ≤3mm ≤5mm
Fit to material Fiberglass Carbon steel, stainless , copper, aluminum, iron, and so on
Fit to shape Round, square, rectangle ,oval, angle steel
Tube and hole size Moulds can be customized as different requirement
Depend on tube material and thickness, also hole size,
Punching hole accuracy 0.01mm
Feed accuracy 0.1mm
Color white , or customized
Feed way Slideway and servo motor
Control way PLC, 10 inch Touch Screen
Clamping way Pneumatic(air compressor is with machine)
programs stored 200 sets, each program store different processing message
Operation language Chinese and English, or customized
Voltage 220V,380V,415V,440v, customized as requirement
Cutting method(option ) Saw blade ,or hydraulic punch cutting


MeasureMeasure
Machine head 1500x100x1700mm

Feed frame
3500x600x12500mm(single,3m feed)
3500x900x12500mm(double,3m feed)
6500x600x12500mm(single,6m feed)
6500x900x12500mm(double,6m feed)

 A mean single head,B mean double heads, feed lenght can be customized
please let us know. what is pipe size, material , and also hole size , in order to recommend suitable machine

The Full Automatic Round Pipe Punching Small Holes Tube Punch and Cut Down Machine is an industrial automated solution designed for efficient punching and cutting of round pipes and metal tubes. It combines automatic material feeding, positioning, small-hole punching, and cutting operations into an integrated production process, helping manufacturers reduce repetitive manual work and improve processing consistency.

Round pipes and tubes are widely used in furniture, automotive components, construction, shelving, fitness equipment, agricultural machinery, metal products, and general fabrication. When a large number of small holes must be produced at specific locations, conventional manual drilling and cutting can require significant labor and repeated measuring. An automatic tube punching and cutting machine provides a more streamlined approach for batch production.

Full Automatic Tube Processing

The machine is designed around an automated workflow in which compatible round tubes are fed into the processing area, positioned according to the programmed requirements, punched with the selected tooling, and then cut to the required length.

Depending on the machine configuration, automatic feeding, clamping, positioning, punching, and cutting functions can be coordinated within one production cycle. This helps reduce unnecessary material handling and provides a more consistent manufacturing process.

Round Pipe Small Hole Punching

The Round Pipe Punching Machine is designed for creating small holes in compatible metal pipes and tubes. Punching can provide an efficient alternative to individual drilling operations when the same hole pattern is repeatedly required.

Hole diameter, spacing, position, material thickness, and pipe dimensions should be considered when selecting the appropriate punching tooling. The machine can be equipped with suitable punches and dies according to the customer's tube specifications.

Automatic Tube Feeding

Automatic feeding helps transfer round pipes or tubes from the material storage area toward the punching and cutting station. A properly configured feeding system can reduce manual loading and improve production continuity.

Depending on the model, the feeding arrangement may include loading racks, rollers, guide systems, clamps, sensors, and automatic transfer mechanisms. The feeding configuration should be selected according to tube length, diameter, weight, and production volume.

Accurate Tube Positioning

Precise positioning is important when small holes need to be punched at predetermined locations. The machine uses controlled movement and clamping to help establish the required processing position before punching.

For products with repeated hole patterns, programmed positioning can reduce manual measurement and marking. This can help manufacturers maintain more consistent hole locations between batches.

Automatic Pipe Cutting

After the punching process, the tube can be cut according to the required production length. Integrating punching and cutting into one machine reduces the need to transfer semi-finished tubes between separate processing stations.

The cutting system can be configured according to the tube material, diameter, wall thickness, and required cutting method. Suitable cutting tooling should be selected according to the actual application.

Punching And Cutting In One Process

Combining hole punching and cutting functions provides a practical solution for manufacturers that need multiple operations on the same round tube.

The automatic production sequence can be arranged to feed the material, position it, perform the required hole punching, and complete the cut. The exact processing sequence depends on machine design and customer requirements.

Consistent Small Hole Patterns

Many tubular products require multiple small holes at regular intervals or specified positions. Automated positioning helps reduce variation that can occur when operators manually measure and drill each tube.

For repetitive production, CNC or programmable control can store processing parameters and help maintain consistent hole locations across multiple workpieces.

Suitable For Metal Tubes

The machine can be configured for suitable steel, carbon steel, stainless steel, galvanized steel, aluminum, and other compatible metal tubes, depending on machine specifications and tooling.

Material hardness, tube diameter, wall thickness, and hole size all influence the required punching force and tooling. Customers should provide complete material information before machine selection.

Applications In Furniture Manufacturing

Round tube punching is commonly required in metal furniture manufacturing. Tables, chairs, shelves, racks, bed frames, storage systems, and other tubular products may require repeated holes for assembly or adjustment.

An automatic punching and cutting machine can help furniture manufacturers process large batches of tubes with repeatable hole patterns and finished lengths.

Automotive And Equipment Components

Tubular components used in automotive accessories, machinery frames, equipment supports, and fabricated metal assemblies may require accurately positioned holes.

Automatic tube processing can simplify repetitive production where the same tube dimensions and hole patterns are used across multiple workpieces.

Efficient Batch Production

Manual drilling and cutting can involve repeated material positioning, measuring, marking, drilling, and cutting. These individual operations can increase production time and labor requirements.

By integrating several processes, the machine can help streamline batch manufacturing and reduce unnecessary workpiece handling. Production efficiency will depend on tube specifications, processing pattern, machine configuration, and operator workflow.

Customized Punching Tooling

Different products require different hole diameters, hole patterns, tube sizes, and punching positions. Customized punches, dies, guides, clamps, and fixtures can therefore be important for specialized production.

Customers can provide tube samples, drawings, hole patterns, material specifications, and production requirements so that suitable tooling can be evaluated.

Stable Clamping And Processing

Stable clamping helps prevent unwanted tube movement during punching and cutting. Proper guides and fixtures can help maintain the position of round tubes throughout the processing cycle.

For longer tubes, appropriate material support and feeding arrangements can further improve stability. The machine configuration should be selected according to the workpiece dimensions and weight.

Reduced Manual Labor

Automatic feeding, positioning, punching, and cutting can reduce repetitive operator intervention. Instead of manually performing every hole and cut, operators can focus on loading materials, monitoring the machine, replenishing components, and inspecting finished products.

This makes automated tube processing particularly useful for factories with stable, repetitive production orders.

Flexible Production Configuration

The machine can be configured according to different tube diameters, lengths, wall thicknesses, hole sizes, hole quantities, and cutting requirements.

For manufacturers producing several types of tubular products, interchangeable tooling and programmable processing parameters can provide additional production flexibility, subject to machine capabilities.

B2B Manufacturing Solution

The Automatic Tube Punching And Cutting Machine is suitable for factories, OEM manufacturers, metal product suppliers, furniture manufacturers, automotive component producers, and other businesses that process round tubes in volume.

Customers can provide product drawings, tube dimensions, material type, hole specifications, finished length, and expected production quantity for machine and tooling evaluation.

Key Features
Full Automatic Tube Processing
Round Pipe Small Hole Punching
Automatic Tube Feeding
Automatic Tube Positioning
Programmable Hole Patterns
Automatic Pipe Cutting
Integrated Punching And Cutting
Stable Tube Clamping
Customized Punches And Dies
Reduced Manual Labor
High Production Efficiency
B2B Custom Machine Configuration
Main Applications
Metal Furniture Manufacturing
Round Tube Processing
Steel Pipe Fabrication
Automotive Components
Storage Rack Production
Metal Shelving
Chair And Table Frames
Bed Frame Manufacturing
Fitness Equipment
Agricultural Machinery
Industrial Equipment
General Metal Fabrication
FAQs
1. What Is A Full Automatic Round Pipe Punching Machine?

It is an automated machine designed to feed, position, punch holes, and cut compatible round pipes or metal tubes according to specified production requirements.

2. Can It Punch Small Holes In Round Tubes?

Yes. The machine can be equipped with suitable punches and dies for small-hole punching, depending on the tube material, wall thickness, diameter, and required hole size.

3. Can Punching And Cutting Be Completed On One Machine?

Yes. The machine integrates tube punching and cutting operations into an automated production process, subject to the selected machine configuration.

4. What Types Of Tubes Can Be Processed?

Suitable applications may include carbon steel, stainless steel, galvanized steel, aluminum, and other compatible metal tubes. Final suitability depends on machine specifications and tooling.

5. Does The Machine Feed Tubes Automatically?

The machine can be equipped with an automatic feeding system using suitable racks, rollers, guides, clamps, or transfer mechanisms according to the production requirements.

6. Can The Hole Position Be Programmed?

Yes. For machines with programmable or CNC control, hole positions and processing sequences can be set according to the required production pattern.

7. Can Different Hole Sizes Be Used?

Different hole sizes may require different punches and dies. Tooling should be selected according to the hole diameter, tube material, and wall thickness.

8. Can It Cut Tubes To Different Lengths?

Yes. The cutting system can process programmed or specified tube lengths within the machine's working range and according to the selected configuration.

9. Can The Machine Be Customized?

Yes. Feeding systems, punching tooling, dies, clamps, guides, fixtures, and control functions can be customized or configured according to customer requirements.

10. What Information Should I Provide Before Ordering?

Provide tube diameter, wall thickness, material, tube length, hole diameter, hole quantity, hole spacing, hole pattern, required finished length, and expected production volume. Product drawings or samples are also helpful.

Why Choose Us
Professional Tube Punching Equipment

We provide industrial machinery for automatic tube punching, pipe hole processing, tube cutting, and integrated metal tube fabrication applications.

Integrated Automatic Production

The machine combines feeding, positioning, punching, and cutting functions to help reduce repeated manual operations and simplify the production workflow.

Customized Tooling Support

Small-hole punching requirements vary between products. We can evaluate suitable punches, dies, clamps, guides, fixtures, and feeding components according to the customer's tube specifications.

Sample And Drawing Evaluation

Customers can provide tube samples, CAD drawings, hole patterns, material specifications, and production requirements. This information helps determine suitable machine and tooling configurations.

Factory Direct B2B Supply

We support overseas manufacturers, OEM factories, distributors, furniture producers, metal product companies, and industrial customers with machine configuration and technical communication.

Production-Focused Solutions

Machine configuration can be selected according to tube dimensions, hole requirements, cutting length, production volume, and desired automation level to create a practical production solution.

International Export Support

We provide technical documentation, operating guidance, packaging, shipping coordination, spare parts support, and after-sales assistance for international customers.
