DXL936 Integrated DTH Surface Drill Rig

Rated Power: 162 kW
Drilling diameter (mm)：φ90-115
Drill pipe type (mm)：φ76*3000

model	936
engine	Cummins QSB5.9-220 (National III)
power（KW）	162
Drill pipe type（mm）	φ76*3000
Drilling diameter（mm）	φ90-115
Maximum working torque（N.m）	2700
Swing speed（rpm）	70-150
Propulsion（kN）	15
Lifting power（kN）	25
Propulsion method	Motor + chain
Leveling angle	±10°
Walking speed（km/h）	1.5-3
Gradeability	30°
gross weight（kg）	9400
Shipping dimensions（mm）	8000*2300*2600
exhaust volume	Displacement 16m³/min. Pressure 16bar

The DXL936 Integrated DTH Surface Drill Rig is a professional integrated drilling solution developed for mining, quarrying, infrastructure construction, and large-scale excavation projects. Combining a powerful air compressor, advanced hydraulic drilling system, durable crawler chassis, and intelligent control technology into one machine, it provides outstanding penetration rates, excellent mobility, reduced fuel consumption, and superior drilling performance in hard rock formations.

DXL936 Integrated DTH Surface Drill Rig
High-Efficiency Integrated Drilling Solution For Modern Surface Mining Operations

The DXL936 Integrated DTH Surface Drill Rig is designed to maximize drilling productivity and operational efficiency for demanding rock drilling applications. By integrating the air compressor, hydraulic system, power unit, and drilling platform into a single machine, the DXL936 offers superior performance, simplified logistics, and lower operating costs compared to traditional separated drilling systems.

Modern mining and quarry operations require drilling equipment capable of delivering accurate blast holes, high penetration rates, and reliable performance under harsh working conditions. The DXL936 meets these requirements through advanced Down-The-Hole drilling technology, intelligent hydraulic controls, heavy-duty structural components, and operator-friendly design.

Its integrated configuration minimizes air pressure loss, improves energy utilization, reduces transportation complexity, and simplifies maintenance procedures. These advantages help contractors achieve higher productivity while lowering total ownership costs.

Whether working in open-pit mines, aggregate quarries, infrastructure projects, hydropower developments, railway construction, or foundation engineering, the DXL936 delivers exceptional drilling performance and long-term reliability.

Fully Integrated Design Advantages

The DXL936 combines multiple systems into a compact and highly efficient drilling platform.

Benefits Of Integrated Design
Reduced Fuel Consumption

Optimized power distribution improves energy efficiency.

Lower Air Pressure Loss

Integrated compressor placement maximizes drilling performance.

Easier Transportation

Single-unit transportation reduces logistics costs.

Faster Deployment

Quick setup allows immediate operation on job sites.

Simplified Maintenance

Integrated systems reduce service complexity.

Improved Equipment Management

One machine is easier to monitor, maintain, and operate.

These advantages make the DXL936 an ideal choice for contractors seeking maximum operational efficiency.

Advanced Down-The-Hole Drilling Technology

The DXL936 utilizes proven Down-The-Hole drilling technology, widely recognized for its efficiency and reliability in hard rock drilling applications.

Advantages Of DTH Technology
High drilling speed
Straight blast holes
Excellent hole quality
Lower energy consumption
Reduced drilling costs
Superior hard rock performance

By placing the hammer directly behind the drill bit, impact energy is transferred efficiently into the rock formation, resulting in faster penetration and improved productivity.

Exceptional Drilling Performance

The DXL936 is engineered for continuous heavy-duty drilling operations.

Key Performance Benefits
High Penetration Rates

Powerful hammer energy accelerates drilling progress.

Stable Rotary Head

Ensures smooth and consistent drilling performance.

High Feed Force

Maintains productivity in challenging rock formations.

Accurate Hole Positioning

Produces straight blast holes with minimal deviation.

Continuous Operation Capability

Designed for long working hours in demanding environments.

These features improve project efficiency while reducing operating expenses.

Advanced Hydraulic Control System

The hydraulic system provides reliable power and precise control for all machine functions.

Hydraulic Features
Smooth drilling operation
Accurate feed control
Adjustable drilling pressure
Stable boom movement
Reliable rotation performance

The optimized hydraulic circuit improves efficiency while minimizing component wear.

Premium hydraulic components ensure long service life and dependable operation.

Heavy-Duty Crawler Undercarriage

The crawler chassis is built for excellent mobility and stability across rugged terrain.

Advantages
Strong climbing ability
Outstanding traction
Stable drilling platform
Reliable off-road capability
Long operational lifespan

The machine performs effectively on:

Open-pit mining sites
Granite quarries
Limestone operations
Mountain construction projects
Road construction zones
Uneven rocky surfaces
High-Strength Drill Boom And Feed Beam

The drill boom system is constructed using reinforced high-strength steel for durability and precision.

Features
Wide drilling coverage
Flexible positioning capability
Precise hole alignment
Stable feed movement
Reduced machine repositioning

The advanced feed system maintains optimal drilling pressure and improves hole quality.

Intelligent Operating System

The DXL936 features an advanced control platform designed for efficiency and ease of operation.

Advantages
User-friendly interface
Real-time machine monitoring
Precise drilling adjustments
Enhanced operator safety
Reduced operator fatigue

The ergonomic operating environment improves comfort during long working shifts.

High-Efficiency Dust Collection System

Environmental protection and workplace safety are critical for modern drilling projects.

Dust Collection Benefits
Reduces airborne dust
Improves visibility
Protects drilling components
Enhances operator safety
Supports environmental compliance

The dust collection system is especially valuable in quarry and urban construction environments.

Applications Of DXL936 Integrated DTH Surface Drill Rig
Open-Pit Mining

Blast hole drilling for coal, gold, iron ore, copper, and other mineral extraction operations.

Quarry Production

Granite, limestone, marble, basalt, sandstone, and aggregate extraction.

Road Construction

Rock excavation and blasting for highways and transportation infrastructure.

Railway Engineering

Foundation preparation and rock cutting operations.

Hydropower Development

Tunnel entrances, dam foundations, and excavation work.

Infrastructure Construction

Municipal engineering and public utility projects.

Foundation Engineering

Rock anchoring, slope stabilization, and piling preparation.

Large Construction Projects

Site preparation and rock removal before structural development.

Advantages Of Choosing DXL936 Integrated DTH Surface Drill Rig
High Productivity

Integrated systems maximize drilling efficiency.

Low Operating Costs

Reduced fuel consumption and maintenance requirements.

Excellent Hole Quality

Produces accurate and consistent blast holes.

Reliable Performance

Designed for continuous industrial operation.

Easy Transportation

Integrated structure simplifies logistics.

Strong Mobility

Crawler undercarriage handles rough terrain effectively.

Long Service Life

Premium components provide exceptional durability.

Built For Harsh Working Environments

The DXL936 is engineered to withstand the toughest mining and construction conditions.

Structural Features
Reinforced steel frame
Heavy-duty hydraulic components
Wear-resistant drilling parts
Industrial cooling systems
Durable crawler tracks
High-performance rotary head

These components ensure dependable performance during continuous heavy-duty operations.

Why Choose Us
Professional Drilling Equipment Manufacturer

Specializing in DTH drilling rigs, mining equipment, quarry machinery, and construction solutions.

Strict Quality Control

Every machine undergoes comprehensive inspection and testing before shipment.

Competitive Factory Pricing

Factory-direct sales provide maximum value and cost savings.

OEM & ODM Customization

Customized colors, logos, specifications, and technical configurations are available.

Worldwide Export Experience

Machines exported successfully to customers worldwide.

Fast Spare Parts Supply

Comprehensive parts inventory minimizes downtime.

Professional After-Sales Service

Technical consultation, installation support, operator training, and lifetime technical assistance are available.

FAQs
1. What is the main advantage of the DXL936 integrated design?

The integrated design combines the compressor and drill rig into one machine, improving efficiency and reducing operating costs.

2. What drilling technology does the DXL936 use?

It uses advanced Down-The-Hole (DTH) drilling technology.

3. Is the machine suitable for hard rock drilling?

Yes. It is specifically designed for medium-hard and hard rock formations.

4. What industries commonly use the DXL936?

Mining, quarrying, road construction, railway engineering, hydropower, and infrastructure development.

5. Does it include a dust collection system?

Yes. A high-efficiency dust collection system is integrated into the machine.

6. Can it operate on rough terrain?

Yes. The crawler undercarriage provides excellent stability and mobility.

7. Is maintenance convenient?

Yes. The integrated design simplifies maintenance and servicing procedures.

8. Can drilling parameters be adjusted?

Yes. Feed force, drilling pressure, and rotation speed can be adjusted according to rock conditions.

9. Is OEM customization available?

Yes. Customized branding, colors, and technical configurations are supported.

10. Do you provide spare parts and technical support?

Yes. Complete spare parts support and professional after-sales service are available.
