BLZ Heavy Duty Chain Conveyor, Coal Cement Chain Conveyor

BLZ Heavy duty chain plate conveyor is designed and improved on the basis of BLQ medium chain plate feeder. We increase rotary parts on both sides of chain plate conveyor in order to convey irregular-shape materials, it takes plate link chain as conveying carrier to achieve conveying material in inclined angle track(0-45°).
It is first choice equipment to convey high temperature material, meanwhile can deliver bulk, massive and granular materials. It is wildly used in building material, metallurgy, mining industries to convey various materials.

Working principle:
There are two chain plates between driving sprocket and bend sprocket,  chain plates connecting one by one, there are two trolley wheels on both side of chain plates, the weight of the material evenly presse on the two wheels, driving device transfer driving force to sprocket, then driving endless chain and chain plates running to achieve the purpose of conveying materials. Comparing with BLQ light duty chain plate conveyor, it is more suitable to conveying material in long distance.
Technical parameter:

BLZ Heavy Duty Chain Conveyor, Coal Cement Chain Conveyor

The BLZ Heavy Duty Chain Conveyor is an industrial bulk material conveying machine designed for continuous and reliable transportation of coal, cement, clinker, ash, minerals, granules, and other heavy-duty materials. Also known as a Coal Cement Chain Conveyor, it uses a robust chain-driven conveying mechanism to move materials through a controlled conveying path.

Compared with conventional belt conveying systems, a heavy-duty chain conveyor is particularly suitable for applications requiring strong mechanical construction, controlled material transportation, and resistance to demanding operating conditions. The system can be used in cement plants, coal handling facilities, power plants, mining operations, metallurgy, building material production, and other bulk material processing industries.

The BLZ conveyor can be designed with a heavy-duty chain, reinforced flights, durable sprockets, industrial gearbox, and robust conveyor housing. Depending on the material characteristics and plant layout, different conveyor lengths, capacities, drive configurations, inlet arrangements, and discharge systems can be supplied.

As a professional heavy duty chain conveyor manufacturer and supplier, we provide standard and customized conveyor solutions for industrial material handling projects.

What Is a BLZ Heavy Duty Chain Conveyor?

A BLZ Heavy Duty Chain Conveyor is a continuous mechanical conveyor that transports bulk materials using a powered chain assembly. The chain moves through the conveyor housing while flights, plates, or scraper components attached to the chain carry or push the material toward the discharge end.

The heavy-duty structure makes the conveyor suitable for dense and abrasive materials such as coal, cement raw materials, clinker, limestone, ash, mineral products, and other bulk solids.

The conveyor can be configured as an enclosed system to help reduce dust and material spillage. This is especially useful for cement and coal handling applications where dust control and clean plant operation are important considerations.

Main Components

A typical BLZ Heavy Duty Chain Conveyor includes:

Heavy-Duty Conveyor Chain
Conveyor Flights or Plates
Conveyor Housing
Drive Sprocket
Tail Sprocket
Drive Motor
Gear Reducer
Chain Tensioning Device
Conveyor Shaft
Bearings
Material Inlet
Discharge Outlet
Inspection Covers
Wear-Resistant Liners

The chain is the primary load-bearing and conveying component. Sprockets engage with the chain and transmit mechanical power from the drive unit.

For applications involving abrasive materials, wear-resistant liners and reinforced conveying components can be selected to improve durability and reduce maintenance requirements.

How Does a Heavy Duty Chain Conveyor Work?

The BLZ conveyor operates through continuous chain movement.

Bulk material enters through the feed inlet and is loaded onto the conveying surface or into the conveyor trough. The electric motor drives the gearbox, which transfers torque to the drive sprocket.

The drive sprocket engages the conveyor chain and moves it continuously along the conveying path. Flights or conveying plates attached to the chain push or carry the material toward the discharge section.

At the outlet, the material is discharged into a hopper, storage system, crusher, mill, elevator, belt conveyor, screw conveyor, packing system, or other downstream equipment.

This continuous mechanical conveying principle allows the BLZ Heavy Duty Chain Conveyor to become part of an automated bulk material handling line.

Coal Chain Conveyor Applications

Coal is a common material handled by heavy-duty chain conveyors. Coal handling systems require equipment capable of transporting large quantities of bulk material while maintaining reliable operation under dusty and abrasive conditions.

The BLZ Coal Chain Conveyor can be used for:

Raw Coal Handling
Coal Feeding
Coal Transfer
Coal Storage Systems
Power Plant Coal Handling
Coal Preparation Plants
Mining Material Transportation

An enclosed conveyor configuration can help reduce airborne dust and material spillage during transportation.

Cement Chain Conveyor Applications

The Cement Chain Conveyor can be used in cement manufacturing and building material production for transporting cement-related bulk materials.

Typical applications include:

Cement Raw Materials
Limestone
Gypsum
Clinker
Cement Powder
Coal
Fly Ash
Alternative Fuels
Other Granular Materials

The conveyor can connect different stages of a cement production line, including feeding, crushing, grinding, storage, blending, and packing processes.

Key Advantages
Heavy-Duty Construction

The BLZ conveyor is designed for demanding industrial applications where strong mechanical construction and continuous conveying are required.

Suitable for Coal and Cement

Its chain-driven design makes it suitable for dense bulk materials such as coal, cement raw materials, clinker, ash, minerals, and other industrial solids.

Continuous Material Handling

The continuous chain provides stable transportation and can support automated production lines.

Enclosed Conveying Option

An enclosed housing helps contain dusty materials and reduce material loss during transportation.

High Load Capacity

The robust chain and structural components can be configured for heavy bulk material loads and demanding conveying conditions.

Abrasion Resistance

For coal, clinker, minerals, and other abrasive materials, wear-resistant components can be incorporated into the conveyor design.

Flexible Layout

The conveyor can be customized according to conveying length, material flow direction, installation space, inlet position, and discharge location.

Easy Integration

The BLZ conveyor can be integrated with feeders, hoppers, crushers, screens, mills, silos, elevators, belt conveyors, screw conveyors, and packing systems.

How to Select the Right BLZ Chain Conveyor

Correct conveyor selection begins with the material characteristics.

The material type should be identified first. Important factors include bulk density, particle size, moisture content, temperature, abrasiveness, and flowability.

The required conveying capacity is also essential. The system should be sized according to the required tons per hour and production schedule.

Next, determine the conveying distance and installation configuration. Longer conveying distances may require different chain specifications, drive power, tensioning arrangements, and structural support.

For cement and clinker applications, material temperature and abrasion should be considered. For coal applications, dust conditions, particle size, moisture, and safety requirements should be evaluated.

The inlet and discharge configuration should also match the surrounding equipment to ensure smooth material flow.

Maintenance and Operation

Regular maintenance is important for reliable operation and long service life.

Operators should inspect the chain, flights, sprockets, bearings, gearbox, motor, tensioning device, and conveyor housing at scheduled intervals.

Chain tension should be maintained within the recommended operating range. Excessive tension can increase mechanical loading and wear, while insufficient tension can cause unstable chain movement.

Wear-resistant liners and scraper components should be inspected regularly, especially when handling abrasive materials such as clinker, coal, minerals, or cement raw materials.

Lubrication should follow the equipment manufacturer's recommendations. Any unusual noise, vibration, overheating, or abnormal chain movement should be investigated promptly.

Before maintenance or inspection, the conveyor should be stopped and isolated from its power source according to applicable industrial safety procedures.

OEM and Custom Chain Conveyor Solutions

Industrial production lines vary considerably in capacity, material type, layout, and operating environment. Therefore, customized conveyor design can provide a better fit for specific applications.

We provide OEM and custom BLZ Heavy Duty Chain Conveyor solutions according to customer requirements.

Customization can include conveyor length, width, chain specification, flight design, drive motor, gearbox, conveying capacity, inlet and outlet configuration, wear-resistant lining, inspection covers, sealing structure, and installation arrangement.

For coal handling systems, the conveyor can be configured according to coal particle size, moisture, density, and required capacity.

For cement plants, the system can be designed for limestone, clinker, cement raw material, ash, gypsum, and other bulk materials.

Why Choose Us?
Heavy-Duty Conveyor Manufacturing: We provide industrial chain conveyor equipment for demanding bulk material handling applications.
Coal and Cement Applications: Our conveyors can be configured for coal, cement raw materials, clinker, ash, limestone, and other industrial materials.
Custom Engineering: Conveyor dimensions, chain specifications, drives, and discharge arrangements can be customized.
Wear-Resistant Options: Heavy-duty chains, flights, and wear-resistant liners are available for abrasive materials.
Complete Conveying Solutions: The conveyor can be integrated with feeders, crushers, mills, hoppers, silos, elevators, and other equipment.
OEM Service: Customized equipment configurations and specifications are available for industrial buyers and distributors.
International B2B Support: We provide technical communication and equipment configuration support for overseas customers and industrial projects.
FAQs
1. What is a BLZ Heavy Duty Chain Conveyor?

A BLZ Heavy Duty Chain Conveyor is a chain-driven industrial conveyor designed for continuous transportation of coal, cement materials, clinker, ash, minerals, and other bulk solids.

2. What materials can the conveyor handle?

It can be configured for coal, cement raw materials, clinker, limestone, gypsum, fly ash, minerals, granular materials, and many other bulk solids.

3. Is the BLZ conveyor suitable for coal handling?

Yes. It can be designed for coal feeding, transfer, storage, and other bulk coal handling applications.

4. Can it be used in cement plants?

Yes. Heavy-duty chain conveyors are suitable for transporting limestone, clinker, cement raw materials, gypsum, ash, coal, and other cement plant materials.

5. Can the conveyor handle abrasive materials?

Yes. Wear-resistant chains, flights, liners, and other components can be selected for abrasive materials such as clinker and minerals.

6. Can the conveyor be enclosed?

Yes. An enclosed conveyor housing can help control dust and reduce material spillage during transportation.

7. What determines the conveyor capacity?

Capacity depends on material density, particle size, conveyor dimensions, chain speed, loading conditions, conveying distance, and system configuration.

8. Can the conveyor length be customized?

Yes. Conveyor length, width, chain type, drive configuration, inlet, and discharge locations can be customized.

9. Can it connect to existing equipment?

Yes. The BLZ conveyor can be connected with feeders, hoppers, crushers, screens, mills, elevators, silos, belt conveyors, and packing equipment.

10. Do you provide OEM Heavy Duty Chain Conveyors?

Yes. OEM and customized chain conveyor solutions can be supplied according to material characteristics, capacity, layout, operating environment, and customer specifications.
