BLQ Light-duty Chain Plate Conveyor, Industrial Waste Drag Chain Metal Scale Plate Conveyor

BLQ chain plate conveyor is designed and improved on the basis of B series medium-size chain plate feeder. It runs in low speed, performance steady and reliable, low failure rate. Chain pate uses 16 manganese steel, 4-5mm thickness. With advantage of low noise, high temperature resistant, large conveying capacity, long service life, it is used widely in mining, electricity, metallurgy, coal, unloading material of rotary kiln, vertical kiln etc. to convey and measure material.

Technical parameter:

BLQ Light-Duty Chain Plate Conveyor, Industrial Waste Drag Chain Metal Scale Plate Conveyor

The BLQ Light-Duty Chain Plate Conveyor is a practical industrial conveying system designed for transporting industrial waste, metal scraps, small parts, components, packaged products, and other materials in manufacturing and material handling operations. Also known as a Metal Scale Plate Conveyor, drag chain conveyor, chain plate conveyor, or metal slat conveyor, this equipment uses a continuous chain-driven plate structure to move materials along a fixed conveying path.

Compared with conventional belt conveyors, chain plate conveyors use durable metal plates or scale-shaped conveying elements connected to a chain system. This construction provides a stable conveying surface for materials that may be sharp, abrasive, hot, irregularly shaped, or unsuitable for a standard rubber belt.

The BLQ light-duty design is intended for applications where moderate conveying capacity, compact construction, reliable operation, and flexible material handling are required. It can be integrated into industrial production lines, waste collection systems, metal processing facilities, recycling plants, assembly lines, and general manufacturing operations.

As an industrial Chain Plate Conveyor manufacturer and supplier, we can provide standard and customized equipment according to conveying capacity, material characteristics, conveyor length, installation space, and production requirements.

What Is a Chain Plate Conveyor?

A Chain Plate Conveyor is a mechanical conveyor that uses a continuous chain and interconnected plates to transport materials. The plates form the conveying surface while the chain provides the driving force.

The BLQ conveyor uses a metal plate or scale plate structure that is suitable for applications where the conveyed material may cause greater mechanical wear than ordinary packaged products.

Industrial waste and scrap materials can have irregular shapes and sharp edges. A metal plate conveying surface provides a more robust handling platform than many flexible belt surfaces.

The conveyor can be configured for horizontal conveying and can be incorporated into automated production and waste handling systems.

Main Components

A typical BLQ Light-Duty Chain Plate Conveyor consists of:

Conveyor Frame
Metal Scale Plates
Conveyor Chain
Drive Sprocket
Tail Sprocket
Drive Motor
Gear Reducer
Support Rails
Bearings
Chain Tensioning Device
Material Inlet
Discharge Section
Safety Guards

The metal scale plates create the main conveying surface. They are connected to the chain assembly and move continuously when the drive system is operating.

The drive motor and reducer provide the necessary torque, while the sprockets engage with and guide the chain.

The conveyor frame provides structural support and can be designed according to the required length and installation environment.

How Does a BLQ Chain Plate Conveyor Work?

The operating principle is based on continuous chain movement.

Material is loaded onto the metal scale plates at the conveyor inlet. The electric motor transfers power through the gearbox to the drive sprocket.

The drive sprocket engages with the conveyor chain and moves the chain and connected metal plates along the conveying path.

As the plates travel forward, they carry industrial waste, metal scraps, components, parts, or other materials toward the discharge end.

At the discharge section, materials can be transferred into a collection container, hopper, processing machine, recycling system, or another conveyor.

The return side of the chain travels beneath or along the conveyor frame before returning to the loading point, creating a continuous circulation loop.

Industrial Waste Drag Chain Conveyor

The Industrial Waste Drag Chain Conveyor is particularly useful for moving manufacturing residues and industrial waste from production equipment to centralized collection or processing areas.

Typical materials may include:

Metal Scrap
Stamping Waste
Machining Chips
Production Offcuts
Small Metal Components
Industrial Residues
Recyclable Materials
Packaging Waste
Manufacturing Debris

For metalworking operations, the metal plate structure can provide a durable conveying surface for sharp or irregular scrap.

The conveyor can also be integrated with machine tools, stamping presses, cutting machines, recycling equipment, shredders, sorting systems, and collection bins.

Metal Scale Plate Conveyor Applications

The Metal Scale Plate Conveyor can be used in many industrial environments.

Metalworking

The conveyor can transport metal scraps, components, offcuts, and production residues generated by cutting, stamping, punching, machining, and fabrication processes.

Recycling

It can move recyclable industrial materials toward sorting, crushing, shredding, or storage equipment.

Manufacturing

Chain plate conveyors can transport components and workpieces between production stations.

Assembly Lines

The stable metal conveying surface is suitable for moving products, parts, fixtures, and containers through manufacturing operations.

Waste Collection

The equipment can collect and transfer production waste from individual machines to centralized waste handling systems.

Industrial Material Handling

Depending on the conveyor configuration, it can transport various solid materials through warehouses, workshops, production areas, and processing facilities.

Key Advantages
Durable Metal Conveying Surface

Metal scale plates provide a strong conveying surface for materials that may damage or wear conventional flexible belts.

Suitable for Industrial Waste

The conveyor is well suited to irregular, sharp, and dense manufacturing waste such as metal scraps and production residues.

Stable Chain Drive

The chain-driven system provides positive mechanical movement and reliable conveying performance.

Compact Structure

The BLQ design can be configured for production lines where installation space is limited.

Flexible Material Handling

The conveyor can transport components, parts, scrap, waste, and other solid materials.

Easy Production Line Integration

The conveyor can connect with machine tools, stamping machines, cutting equipment, recycling systems, hoppers, bins, and other conveyors.

Customizable Design

Length, width, plate dimensions, chain specifications, drive arrangement, support structure, and discharge configuration can be customized.

Easy Maintenance

The chain, sprockets, plates, bearings, and drive components can be inspected and maintained individually.

How to Select the Right Chain Plate Conveyor

Several factors should be considered when selecting a BLQ Chain Plate Conveyor.

First, identify the material characteristics. Consider the material's weight, dimensions, shape, temperature, abrasiveness, moisture, and potential sharp edges.

Next, determine the required conveying capacity. The conveyor should be sized according to the expected material flow and production requirements.

The conveyor length and width should match the available installation area and the size of the material being transported.

For metal scrap applications, the size and shape of scrap are especially important. Large or sharp pieces may require reinforced plates and a stronger chain system.

The operating environment should also be evaluated. Workshop environments, recycling facilities, outdoor installations, dusty areas, and wet conditions may require different frame, plate, and protective configurations.

Maintenance and Operation

Routine maintenance helps ensure reliable conveyor operation.

Operators should regularly inspect the chain, metal plates, sprockets, bearings, drive motor, gearbox, support rails, and tensioning system.

The chain should maintain appropriate tension. Excessive tension can increase mechanical loading, while insufficient tension can cause unstable movement or chain disengagement.

Metal plates should be checked for deformation, excessive wear, cracks, or loose connections.

Sprockets should be inspected for tooth wear, especially in applications with frequent starts and stops or heavy scrap loads.

Lubrication should follow the manufacturer's recommendations for the chain, bearings, gearbox, and other applicable components.

Before maintenance or cleaning, the conveyor should be stopped and isolated from its power supply according to appropriate industrial safety procedures.

OEM and Custom Chain Plate Conveyor Solutions

Every industrial production line has different conveying requirements. We provide OEM and customized BLQ Chain Plate Conveyor solutions according to the customer's application.

Customization can include conveyor length, width, metal plate type, plate thickness, chain specification, drive motor, gearbox, support frame, safety guards, inlet arrangement, discharge configuration, and conveyor height.

For metal scrap handling, the conveying surface and chain system can be selected according to the size, weight, sharpness, and volume of the scrap.

For manufacturing and assembly applications, the conveyor can be configured for specific product dimensions, production speed, workstation spacing, and automation requirements.

Why Choose Us?
Industrial Conveyor Manufacturing: We provide chain plate and drag chain conveyor equipment for manufacturing and material handling applications.
Metal Scrap Handling: The metal plate design is suitable for industrial waste, machining scrap, offcuts, and recyclable materials.
Custom Engineering: Conveyor dimensions, plate design, chain configuration, and drive systems can be customized.
Durable Construction: Appropriate metal plates, chains, sprockets, and support components can be selected for the application.
Production Line Integration: Conveyors can connect with machine tools, stamping presses, recycling equipment, hoppers, bins, and other machinery.
OEM Service: Customized equipment is available for industrial users, engineering companies, distributors, and system integrators.
B2B Export Support: We provide technical communication and configuration support for international industrial customers.
FAQs
1. What is a BLQ Light-Duty Chain Plate Conveyor?

It is a chain-driven conveyor that uses metal plates as the conveying surface for transporting industrial waste, components, scrap, and other solid materials.

2. What is a Metal Scale Plate Conveyor?

A Metal Scale Plate Conveyor uses overlapping or interconnected metal plates driven by a chain to create a durable material conveying surface.

3. What materials can it transport?

It can handle metal scrap, industrial waste, components, parts, production residues, recyclable materials, packaging, and many other solid materials.

4. Is it suitable for metal scrap?

Yes. The metal plate conveying surface is suitable for many metalworking and scrap handling applications.

5. Can it be used in recycling plants?

Yes. It can be integrated into recycling lines for collecting and transporting recyclable industrial materials.

6. What is the difference between a chain plate conveyor and a belt conveyor?

A chain plate conveyor uses mechanically driven metal plates connected to chains, while a belt conveyor uses a continuous flexible belt.

7. Can the conveyor length and width be customized?

Yes. Length, width, plate dimensions, chain specifications, conveyor height, and drive configuration can be customized.

8. Can it connect to production machinery?

Yes. The conveyor can be connected to machine tools, stamping equipment, cutting machines, recycling systems, collection bins, hoppers, and other equipment.

9. Is BLQ suitable for heavy materials?

The BLQ is a light-duty model, so the actual load capacity should be selected according to material weight, conveyor dimensions, and operating conditions.

10. Do you provide OEM Chain Plate Conveyors?

Yes. We provide OEM and custom conveyor solutions based on material characteristics, capacity, layout, and customer specifications.
