788F Backhoe Loader

HZM788F Backhoe Loader Advantage


1. Versatile Functionality

Combines loading and digging capabilities in one machine, offering outstanding flexibility, efficiency, and cost performance for different job applications.
2. Reliable Core Components

Equipped with XCMG axles and transmission, providing strong durability, stable operation, and long-term reliability.
3. Advanced Hydraulic Performance

Features an imported Italian hydraulic system with a load-sensing valve for faster response, smoother operation, and precise control.
The HZM788F Backhoe Loader is powered by a reliable Yuchai YC4A105Z-T20 engine, delivering 75 kW of strong and efficient performance for demanding applications. It features a ROPS safety cab with air conditioning, providing operators with a safe, comfortable, and productive working environment. Equipped with XCMG wet-drive axles and an electronically controlled transmission, the machine ensures smooth power transfer, stable operation, and long-term durability.

The advanced hydraulic system adopts imported Italian load-sensing valves and a plunger pump, offering powerful hydraulic output, fast response, and precise control. A Danfoss steering unit with a priority valve further improves steering accuracy and operating efficiency, while the seat-integrated pilot joystick and H-leg hydraulic side-shift system allow smooth and flexible operation in different working conditions.

Additional features include a rear hydraulic breaker pipeline, heavy-duty tires (Front 14-17.5 / Rear 19.5L-24), a rear-view camera, and a VARTA battery for reliable starting performance. The switchable 2WD / 4WD drive system provides excellent adaptability, making the HZM788F an ideal solution for a wide range of challenging job sites.Product Specifications

Engine Details
(1) Model:		YUCHAI YC4A105Z-T20
(2) Rated Power:		75kw
(3) Rated Speed:		2200R/MIN
Operating Specifications (Loader)
	Standard bucket		6 in 1 bucket
Max dump height under bucket at 45°	2829mm		2829mm
Max height pin	3500mm		3500mm
Dump angle	55°		55°
Below ground level digging depth	92mm		92mm
(1) Bucket Capacity :	1.2CBM		1.2CBM
(2) Loading Capacity:	2500KG		2000KG
(3) Operation Weight:	8800KG		9320KG
Operating specifications( Backhoe )
Max.Reach From Swing Center:	5587mm		6420mm
Max operating height	5562mm		6246mm
Max loading height	3586mm		4270mm
Max digging depth	3623mm		4643mm
Bucket rotation	200°		200°
Bucket Capacity :	0.3cbm		0.3cbm
Max.Digging Force:	5100KGF		5100KGF
Swinging angle	190°		190°
Overall Dimensions
G  Boom height	3506mm		3506mm
O  Wheel base	2285mm		2285mm
P  Cab height	2950mm		2950mm
Q  Overall width	2220mm		2220mm
S  Overall length boom fold	5934mm		5934mm
Bucket width	2450mm		2420mm
Min.Ground Clearance:	450mm		450mm
Tyre
14-17.5(front)		19.5L-24(rear)

Powerful Tractor Loader Backhoe For Construction And Earthmoving

The 788F Backhoe Loader is a multi-purpose heavy-duty machine designed to handle a wide range of construction, agricultural, municipal, and industrial applications. Combining the functions of a front wheel loader and a rear excavator, this machine provides excellent versatility for digging, loading, lifting, trenching, and material transportation tasks.

Instead of using separate machines for excavation and loading operations, the 788F Backhoe Loader offers an efficient all-in-one solution that helps reduce equipment costs, improve job site productivity, and simplify machine management.

With a durable structure, powerful hydraulic system, strong digging performance, and excellent mobility, the 788F is an ideal choice for contractors, construction companies, agricultural operators, and infrastructure professionals.

Two Machines In One Versatile Equipment Solution

The biggest advantage of the 788F Backhoe Loader is its combination of loader and excavator functions.

Front Loader Functions

The front bucket is designed for:

Material loading
Soil handling
Sand and gravel transportation
Snow removal
Site cleanup
Material stacking
Rear Backhoe Functions

The rear excavator attachment provides:

Trenching
Foundation digging
Pipeline installation
Drainage work
Excavation projects
Ground preparation

This combination allows operators to complete multiple tasks with one machine.

Powerful Hydraulic System

The 788F Backhoe Loader uses an advanced hydraulic system to provide smooth and efficient operation.

Hydraulic Advantages
Strong digging force
Fast lifting performance
Precise attachment control
Smooth operation
Reliable working efficiency
Reduced operator fatigue

The hydraulic system ensures excellent performance during heavy-duty excavation and loading operations.

Heavy Duty Construction Performance

The 788F is built for demanding working environments.

Durable Features
Reinforced frame structure
Heavy-duty loader arm
Strong backhoe boom
Durable hydraulic components
Reliable drivetrain
Long service life

The robust construction allows the machine to perform consistently on construction sites, farms, and industrial projects.

4WD Capability For Challenging Terrain

The four-wheel-drive system provides excellent traction and mobility.

4WD Benefits
Improved ground grip
Better performance on rough terrain
Strong climbing ability
Stable operation on muddy surfaces
Enhanced job site mobility
Reliable outdoor performance

The 788F Backhoe Loader can operate effectively in various working conditions.

Construction Applications

The 788F Backhoe Loader is widely used in construction projects.

Construction Uses
Building foundation excavation
Road construction
Trenching projects
Site preparation
Material loading
Construction cleanup

Its versatility makes it a valuable machine for contractors and builders.

Agricultural Applications

The 788F provides excellent support for agricultural operations.

Farm Applications
Land preparation
Irrigation trenching
Farm road maintenance
Material handling
Ditch digging
Agricultural construction projects

Farm owners can use one machine for multiple maintenance and development tasks.

Municipal And Infrastructure Applications

The 788F Backhoe Loader is suitable for public works projects.

Municipal Uses
Pipeline installation
Drainage construction
Road maintenance
Utility trenching
Landscaping projects
Public facility construction

Its flexibility makes it ideal for city and infrastructure work.

Excellent Digging Performance

The rear backhoe attachment provides strong excavation capability.

Digging Advantages
Deep excavation ability
Strong breakout force
Precise digging control
Efficient trenching
Stable operation
Suitable for various soil conditions

The 788F helps operators complete excavation tasks quickly and accurately.

Efficient Loading Capability

The front loader improves material handling efficiency.

Loading Benefits
Large bucket capacity
Fast loading cycles
Easy material movement
Strong lifting capability
Improved productivity
Reduced manual labor

The loader function makes transportation and site cleanup easier.

Operator Friendly Design

The 788F Backhoe Loader is designed for comfortable and efficient operation.

Operator Benefits
Comfortable control layout
Excellent visibility
Easy attachment operation
Reduced vibration
Simple controls
Improved working comfort

A comfortable operator can maintain higher productivity during long working hours.

Fuel Efficient And Cost Effective

The 788F provides excellent value for businesses.

Economic Benefits
Lower equipment investment
Reduced machine requirements
Multi-purpose operation
Lower maintenance costs
Improved productivity
Long-term reliability

One backhoe loader can replace multiple individual machines.

Wide Range Of Attachments

The 788F Backhoe Loader can work with different attachments.

Compatible Attachments
Standard loader bucket
Hydraulic breaker
Pallet fork
Auger attachment
Grapple attachment
Snow removal blade

Attachment flexibility expands machine applications.

Why Choose Us
Professional Construction Equipment Manufacturer

We specialize in manufacturing reliable construction machinery and agricultural equipment.

Strict Quality Inspection

Every 788F Backhoe Loader is tested to ensure performance, durability, and safety.

Factory Direct Pricing

We provide competitive prices with consistent manufacturing quality.

Advanced Manufacturing Technology

Modern production processes ensure machine reliability and precision.

Customized Solutions

Different configurations, attachments, and specifications are available.

Global Export Experience

Our equipment serves customers in international markets.

Fast Delivery

Efficient production management ensures timely shipment.

Complete Technical Support

Professional installation guidance and after-sales service are provided.

Durable Machine Quality

Built for construction, agriculture, infrastructure, and industrial applications.

Long-Term Partnership

We focus on reliable equipment and customer satisfaction.

FAQs
Q1: What is a 788F Backhoe Loader?

A: The 788F Backhoe Loader is a combined loader and excavator machine designed for digging, loading, and material handling operations.

Q2: What jobs can the 788F perform?

A: It can perform excavation, trenching, loading, lifting, earthmoving, road maintenance, and material transportation tasks.

Q3: Is the 788F suitable for construction sites?

A: Yes. It is widely used for construction, infrastructure, and earthmoving projects.

Q4: Can the 788F be used for farming?

A: Yes. It is suitable for land preparation, drainage work, and farm maintenance.

Q5: What is the advantage of a backhoe loader?

A: A backhoe loader combines excavation and loading functions, reducing the need for multiple machines.

Q6: Does the 788F support attachments?

A: Yes. Various attachments can expand its working applications.

Q7: Can it operate on rough terrain?

A: Yes. The 4WD system provides strong mobility and traction.

Q8: Is the hydraulic system reliable?

A: Yes. The hydraulic system is designed for smooth and efficient heavy-duty operation.

Q9: Who uses the 788F Backhoe Loader?

A: Contractors, construction companies, farmers, municipalities, and infrastructure operators.

Q10: Why choose the 788F Backhoe Loader?

A: It offers versatility, strong performance, durability, and excellent cost efficiency.
