45-17 Compact Backhoe Loader

HZM45-17 Mini Backhoe Loader Advantage

1.Reliable Power & Smooth Operation

Equipped with a YUNNEI YN27 42 kW engine and joystick control for stable power output and easy handling.

2. Versatile Dual-Function Design

Comes with a 0.8 m³ front bucket and 0.2 m³ backhoe bucket, plus 3 hydraulic lines for multiple attachments and flexible job applications.

3. Enhanced Operator Comfort

Features a rotating seat, cab heater, engine heater, and a floating function to ensure comfortable and efficient operation in all seasons.

4. Clear Visibility & Safety

LED lamps and a large rear-view camera improve visibility and safety during night work and tight-area operations.

This mini backhoe loader is powered by a reliable YUNNEI YN27 42 kW engine and features joystick control, 3 hydraulic lines, and both a 0.8 m³ front bucket and 0.2 m³ backhoe bucket for versatile dual-end operation. It offers excellent operator comfort with a rotating seat, cab heater, engine heater, and a floating function for smoother work. Safety and visibility are enhanced with LED lamps and a large rear-view camera, while the hub reduction axles and 20.5/70-16 tires ensure durability, strong traction, and stable performance on all terrains.

Product Specifications

HZM45-17 BACKHOE LOADER  parameter
Total Length(BACKHOE ARM SIDE PLACE)	5000/5300MM
Total Height	2850mm
Total Width	1960mm
Total Operating Weight	5160kg
Rear Backhoe Parameter
Rated Backhoe Bucket Capacity	0.2
Max. Digging Depth	1930mm
Max. Digging Height	3800mm
Max. Digging Radius	3510mm
Turning Angle of Movable Arm	180°
Front Loading Parameter
Rise Height	3700mm
Discharge Height	2700mm
Min. Turning Radius	4800mm
Discharge Distance	1110mm
Rated Loading Weight	1600kg
Rise Time of Movable Arm	3.5s
Fall Time of Movable Arm	2.5s
Comprehensive Time	7s
Engine
Engine Model	YUNNEI YN27
Rated Power of Engine	42kw
Engine Flux	40ml/r
Work Pressure	16~18Mpa
Max. Grade Ability	25%
Walking Speed	18~28km/h
Min. Ground Clearance	260mm
Wheel Base	2000mm
Tread	1530mm

45-17 Compact Backhoe Loader
Versatile Mini Tractor Loader Backhoe For Construction And Agricultural Applications

The 45-17 Compact Backhoe Loader is a powerful and flexible multi-purpose machine designed for customers who need professional excavation and loading performance in a compact package. Combining a front loader bucket with a rear hydraulic backhoe attachment, this machine provides two essential functions in one efficient unit.

Designed for small construction projects, agricultural operations, landscaping, municipal work, and property maintenance, the 45-17 Compact Backhoe Loader delivers excellent productivity while maintaining easy transportation and operation capabilities.

Compared with large construction equipment, compact backhoe loaders provide significant advantages in restricted areas. They can access narrow job sites, operate around buildings, work in gardens, and perform excavation tasks where larger machines cannot efficiently operate.

The 45-17 model is an ideal choice for contractors, farmers, landscapers, utility companies, and equipment rental businesses requiring reliable and economical earthmoving equipment.

Compact Size With Powerful Performance

The biggest advantage of the 45-17 Compact Backhoe Loader is its combination of small dimensions and strong working capability.

Compact Backhoe Advantages
Easy operation in confined spaces
Excellent maneuverability
Lower transportation requirements
Suitable for residential projects
Reduced ground disturbance
Flexible job site movement

Although compact in size, the 45-17 provides impressive digging, loading, and material handling performance for various applications.

Two Functions In One Machine

The 45-17 Compact Backhoe Loader combines a loader and excavator into a single versatile machine.

Front Loader Function

The front bucket is suitable for:

Soil loading
Sand and gravel handling
Material transportation
Site cleanup
Snow removal
Landscaping preparation
Rear Backhoe Function

The rear excavator provides:

Trenching
Foundation digging
Pipeline installation
Drainage work
Cable laying
Ground excavation

This combination helps reduce equipment costs and increases job site efficiency.

Powerful Hydraulic System

The hydraulic system provides smooth and reliable machine operation.

Hydraulic Performance Benefits
Strong digging force
Efficient lifting capability
Precise attachment control
Smooth operation
Fast working cycles
Reduced operator effort

The hydraulic system allows the 45-17 to handle demanding excavation and loading tasks with confidence.

4WD Capability For Different Terrains

The 45-17 Compact Backhoe Loader is designed for reliable operation in various environments.

Four Wheel Drive Advantages
Improved traction
Better stability
Strong climbing capability
Suitable for uneven terrain
Reliable outdoor performance
Increased job site mobility

The 4WD system allows operators to work effectively on farms, construction sites, gravel roads, and outdoor projects.

Construction Applications

The 45-17 Compact Backhoe Loader is widely used in construction industries.

Construction Uses
Building foundation excavation
Trenching projects
Road maintenance
Site preparation
Material loading
Construction cleanup

Its compact design makes it especially useful for small and medium-sized construction projects.

Agricultural Applications

The 45-17 provides excellent support for farming operations.

Farm Applications
Land preparation
Irrigation trenching
Farm road maintenance
Material handling
Drainage construction
Agricultural infrastructure projects

Farm owners can complete multiple tasks without requiring separate machines.

Landscaping And Property Maintenance

The compact backhoe loader is highly suitable for landscaping professionals.

Landscaping Uses
Garden excavation
Tree planting preparation
Soil movement
Rock handling
Park maintenance
Residential improvement projects

Its compact size allows operation in areas with limited access.

Utility And Municipal Applications

The 45-17 is suitable for various utility projects.

Utility Applications
Pipe installation
Cable trenching
Drainage systems
Underground service preparation
Municipal maintenance
Small infrastructure projects

The machine provides efficient excavation capability for utility contractors.

Durable Construction Design

The 45-17 Compact Backhoe Loader is built for long-term reliability.

Structural Features
Reinforced machine frame
Durable loader arms
Strong backhoe boom
Heavy-duty hydraulic components
Reliable drivetrain
Long service life

The robust construction ensures stable performance during continuous operation.

Attachment Compatibility

The 45-17 can be equipped with different attachments to expand applications.

Available Attachments
Standard loader bucket
Hydraulic breaker
Auger attachment
Pallet fork
Grapple attachment
Snow blade
Quick hitch system

Attachment flexibility makes this machine suitable for year-round operation.

Operator Friendly Design

The 45-17 Compact Backhoe Loader focuses on comfort and efficiency.

Operator Benefits
Comfortable operating position
Clear visibility
Simple controls
Easy attachment operation
Reduced fatigue
Improved productivity

A user-friendly design helps operators complete tasks efficiently.

Cost Effective Compact Construction Equipment

The 45-17 provides excellent value for small businesses and professional users.

Economic Advantages
Lower purchase investment
Reduced maintenance costs
Multi-purpose capability
Lower transportation costs
High productivity
Long equipment lifespan

One compact backhoe loader can replace several individual machines.

Wide Range Of Applications

The 45-17 Compact Backhoe Loader is suitable for:

Construction contractors
Farmers
Landscaping companies
Utility operators
Property maintenance businesses
Rental equipment companies

Its versatility makes it a valuable machine for many industries.

Why Choose Us
Professional Machinery Manufacturer

We specialize in producing reliable construction machinery, agricultural equipment, and compact earthmoving solutions.

Strict Quality Control

Each 45-17 Compact Backhoe Loader is tested to ensure durability and performance.

Factory Direct Supply

We provide competitive pricing with stable manufacturing quality.

Customized Solutions

Different configurations, attachments, and specifications can be provided according to customer requirements.

Advanced Manufacturing Technology

Modern production processes ensure machine reliability and precision.

Global Export Experience

Our equipment is supplied to customers worldwide.

Fast Delivery

Efficient production management ensures timely shipment.

Technical Support

Professional installation guidance and after-sales support are available.

Durable Product Quality

Machines are designed for construction, farming, landscaping, and industrial applications.

Long-Term Partnership

We focus on reliable equipment solutions and customer satisfaction.

FAQs
Q1: What is the 45-17 Compact Backhoe Loader?

A: The 45-17 Compact Backhoe Loader is a small tractor loader backhoe combining front loading and rear excavation functions.

Q2: What applications can it handle?

A: It can perform digging, loading, trenching, landscaping, farming, road maintenance, and material handling tasks.

Q3: Is the 45-17 suitable for small construction sites?

A: Yes. Its compact design allows operation in limited working areas.

Q4: Can it be used for agricultural work?

A: Yes. It is suitable for farm roads, drainage, land preparation, and material transportation.

Q5: Does it support attachments?

A: Yes. Various attachments can expand its working capabilities.

Q6: What are the advantages of a compact backhoe loader?

A: Compact size, easy transportation, flexible operation, lower cost, and multi-purpose functionality.

Q7: Can it operate on rough terrain?

A: Yes. The 4WD system provides reliable traction and stability.

Q8: Is maintenance difficult?

A: No. The machine is designed for convenient maintenance and servicing.

Q9: Who uses compact backhoe loaders?

A: Contractors, farmers, landscapers, utility companies, and rental businesses.

Q10: Why choose the 45-17 Compact Backhoe Loader?

A: It provides powerful performance, compact operation, versatility, and excellent cost efficiency.
