FCY70R Site Dumper

FCY70 4 Wheel Drive All Terrain Vehicle Dumper for Sale Mini Dumper Truck Hydraulic Tipper Lorry Concrete Dumper with CE Approve A dumper is a vehicle designed for carrying bulk material, often on building sites. Dumpers are distinguished from dump trucks by configuration: a dumper is usually an open 4-wheeled vehicle with the load skip in front of the driver, while a dump truck has its cab in front of the load.

SPECIFICATIONS OF MINI DUMPER FCY-70
General
NO.	Item	Specifications
1.	Payload	7000kg
2.	Operating weight	4550 kg
3.	Hopper capacity	3.5m3
4.	Maximum speed	25 km/h
5.	Handbrake available on grade	18%
6.	Max grade ability	251%
7.	Distance of road after brake	≤2.5m with load and speed 10km/h
8.	Minimum turn radius	4 m
9.	Ground clearance	248 mm
10.	Noise level	≤102 db(A)
11.	Loading discharge angle	48.40
12.	Time of discharge	6s
13.	Hydraulic pressure	16 Mpa
14.	Wheel base	2200 mm
15.	Wheel tread	1580 mm
16.	Engine power	60KW
17.	Dimensions (LxWxH)	5250x2250x2700 mm
B. Engine
1.	Model/Maker	4108 – YC
2.	Type	Diesel 4 stroke engine, 4-cylinder incline, direct fuel injection, water cooled
3.	Bore x stroke piston	100 x 102 mm
4.	Power	60KW
5.	Speed	2400 R/Min
6.	Max t	120@2100v/p
7.	Weight	350 kg
8.	Fuel consumption	248 g/kWh
C. Drive System
1.	Clutch	Single disc, dry type, constant.
	Diameter	254 mm
2.	Transmission:	Hydraulic type
3.	Drive shaft:	Tubular-type, open-type, rigid needle-bearing universal joint
4.	Driving axle:	Main drive type: single-stage hyperbolical bevel gear dive
5.	Final driving	full floating
	Different:	hyperbolical bevel gear dive
D. Frame
1.	Frame:	Channel steel welding type, two-section articulated connection
2.	Tire:	20.5/70-16
3.	wheel ring:	9.75H
E. Steering system 1. Type Control by wheel, full hydraulic system, two cylinders double acting. 2. Angle steering each direction ± 300 F. Bake system
1.	Type	Control by wheel, full hydraulic system, two cylinders double acting.
2.	Angle steering each direction	± 300
1.	Operating brake	Hydraulic shoe system, four wheel mounted.
2.	Handbrake	mechanically-pirated central sport-type disc
G. Hydraulic system
1.	Hydraulic pump:	Gear pump

Heavy Duty Hydraulic Dumper For Professional Material Transportation

The FCY70R Site Dumper is a powerful and versatile material transport machine designed for construction, mining, agriculture, municipal engineering, and industrial applications. Built for challenging job sites, this 7 ton hydraulic dumper combines strong carrying capacity, reliable performance, and excellent maneuverability to improve transportation efficiency.

Compared with traditional transport vehicles, the FCY70R Site Dumper is specifically designed for short-distance bulk material handling in difficult environments. Its compact structure, four-wheel drive system, and hydraulic dumping function make it suitable for construction sites, gravel roads, farms, mines, and areas where large trucks cannot operate efficiently.

The machine provides an economical and productive solution for contractors, builders, farmers, mining operators, and rental companies requiring dependable off-road transportation equipment.

Powerful 7 Ton Loading Capacity

The FCY70R provides excellent carrying performance for heavy-duty applications.

Heavy Load Advantages
Up to 7 ton material transportation capability
Strong dump body structure
Stable operation under heavy loads
Suitable for bulk material movement
Improved job site productivity
Reduced manual transportation

The large capacity design allows operators to move more material in fewer trips, improving overall efficiency.

Hydraulic Dumping System

The advanced hydraulic tipping system allows fast and efficient unloading.

Hydraulic Dump Benefits
Quick unloading operation
Smooth lifting performance
Reduced labor requirements
Improved working speed
Reliable hydraulic control
Easy material discharge

Operators can transport and unload soil, sand, gravel, and construction materials quickly.

Four Wheel Drive Off Road Performance

The FCY70R Site Dumper is designed for demanding terrain conditions.

4WD Advantages
Excellent traction
Stable operation on rough ground
Improved climbing ability
Suitable for muddy areas
Better performance on gravel roads
Reliable outdoor operation

The four-wheel drive system helps maintain productivity in challenging working environments.

Ideal Construction Site Dumper

The FCY70R is widely used in construction projects.

Construction Applications
Moving excavated soil
Transporting concrete
Carrying sand and gravel
Removing construction waste
Foundation preparation
Road construction support

Its strong transport capability makes it an important machine for modern construction operations.

Mining And Quarry Material Transport

The heavy-duty design makes the FCY70R suitable for mining-related applications.

Mining Uses
Stone transportation
Ore movement
Quarry material handling
Short-distance hauling
Mine site support
Heavy material transport

The durable structure provides reliable performance in harsh environments.

Agricultural And Farm Applications

The FCY70R is also suitable for agricultural operations.

Farm Applications
Moving soil
Transporting fertilizer
Carrying feed materials
Farm road maintenance
Land improvement projects
Agricultural material handling

It helps farmers reduce labor intensity and improve operational efficiency.

Strong And Durable Construction

The FCY70R Site Dumper is built for long-term professional use.

Construction Features
Heavy-duty steel frame
Reinforced hopper design
Durable chassis
Reliable hydraulic components
Strong load-bearing structure
Long service life

The machine is designed to withstand repeated operation in demanding working conditions.

Excellent Maneuverability

Although designed for heavy-duty work, the FCY70R provides flexible operation.

Maneuverability Benefits
Compact working design
Easy site movement
Suitable for restricted areas
Efficient turning capability
Better job site accessibility
Reduced transportation limitations

This makes it practical for both large and small projects.

Versatile Material Handling Machine

The FCY70R can transport various materials.

Suitable Materials
Soil
Sand
Gravel
Concrete
Stones
Coal
Construction waste
Agricultural products

Its versatility allows use across multiple industries.

Comfortable Operator Experience

The machine is designed to improve operator efficiency.

Operator Benefits
Easy controls
Clear operation system
Comfortable driving position
Reduced fatigue
Improved working confidence
Simple operation process

A comfortable operator helps maintain productivity during long working hours.

Cost Effective Heavy Equipment Solution

The FCY70R provides excellent value compared with larger transport trucks.

Economic Advantages
Lower operating costs
Reduced labor requirements
High transportation efficiency
Multi-industry applications
Long equipment lifespan
Strong return on investment

It is an ideal choice for companies needing reliable transport equipment.

Applications Across Industries

The FCY70R Site Dumper is suitable for:

Construction companies
Mining operations
Agricultural businesses
Landscaping contractors
Municipal projects
Industrial facilities
Equipment rental companies

Its strong performance makes it a versatile professional machine.

Why Choose Us
Professional Machinery Manufacturer

We specialize in manufacturing construction machinery, agricultural equipment, and material handling solutions.

Strict Quality Control

Each FCY70R Site Dumper undergoes professional inspection to ensure reliability and performance.

Factory Direct Supply

Competitive pricing with consistent manufacturing quality.

Advanced Production Technology

Modern manufacturing processes improve durability and precision.

Customized Solutions

Different configurations, engines, and specifications can be provided according to customer requirements.

Global Export Experience

Our equipment serves customers in different international markets.

Fast Delivery

Efficient production management ensures reliable delivery schedules.

Technical Support

Professional equipment guidance and after-sales service are available.

Durable Equipment Quality

Designed for heavy-duty construction, mining, and agricultural environments.

Long-Term Partnership

We focus on providing dependable machinery and customer satisfaction.

FAQs
Q1: What is the FCY70R Site Dumper?

A: The FCY70R Site Dumper is a 7 ton hydraulic material transport machine designed for construction, mining, farming, and industrial applications.

Q2: What is the loading capacity of the FCY70R?

A: The FCY70R is designed with a rated loading capacity of approximately 7 tons.

Q3: Does the FCY70R have hydraulic dumping?

A: Yes. It features a hydraulic tipping system for fast unloading.

Q4: Where can the FCY70R be used?

A: It can be used in construction sites, mines, farms, roads, landscaping projects, and industrial operations.

Q5: Can it operate on rough terrain?

A: Yes. The 4WD system provides strong traction for uneven and off-road environments.

Q6: What materials can it transport?

A: Soil, gravel, sand, concrete, stones, waste materials, and agricultural products.

Q7: Is the FCY70R suitable for mining?

A: Yes. Its heavy-duty structure makes it suitable for quarry and mining support applications.

Q8: Is maintenance difficult?

A: No. Regular inspection and routine maintenance are sufficient for reliable operation.

Q9: Why choose a hydraulic site dumper?

A: Hydraulic dumpers provide faster unloading, higher efficiency, and reduced manual labor.

Q10: Why choose the FCY70R Site Dumper?

A: It combines heavy load capacity, strong durability, off-road capability, and efficient material transport performance.
