SP480 DTH Hammer

SP480 DTH Hammer
Powerful Down The Hole Drilling Solution For Mining And Construction

The SP480 DTH Hammer is an advanced pneumatic drilling component designed to provide efficient and reliable rock-breaking performance in demanding drilling environments.

As a key component of a DTH drilling system, the hammer is installed behind the drill bit and uses compressed air to drive the piston, generating powerful impact energy directly at the bottom of the borehole. This design minimizes energy loss and improves drilling efficiency, especially in hard rock formations.

The SP480 DTH Hammer is widely applied in:

Mining operations
Quarry blasting
Marble and stone extraction
Water well drilling
Foundation construction
Rock excavation projects

With optimized internal structure, durable materials, and efficient energy transmission, the SP480 provides stable drilling performance while reducing operating costs.

Advanced DTH Hammer Technology

The SP480 DTH Hammer adopts modern pneumatic impact technology to achieve efficient rock penetration.

Working Principle

During drilling operation:

Compressed air enters the hammer through the drill string.
Air pressure drives the internal piston movement.
The piston creates repeated impact forces.
Impact energy is transferred directly to the drill bit.
Rotation and impact together break the rock formation.

This direct impact method provides:

High impact efficiency
Faster drilling speed
Lower energy loss
Better hole accuracy
Improved drilling productivity
High Impact Energy Performance

The SP480 DTH Hammer is designed to deliver powerful impact performance for challenging geological conditions.

Performance Advantages
Strong Rock Breaking Capability

The hammer generates large impact energy to penetrate:

Granite
Limestone
Marble
Basalt
Hard rock formations
Stable Impact Frequency

Optimized piston movement ensures consistent drilling performance.

Efficient Energy Transfer

The short distance between hammer and drill bit improves impact efficiency.

Durable Internal Structure

The SP480 DTH Hammer uses high-quality materials and precision manufacturing technology to improve reliability.

Main Components

The hammer structure includes:

Top Sub
Check Valve
Valve Seat
Inner Cylinder
Piston
Piston Case
Guided Sleeve
Drive Chuck
Drill Bit Connection

These components work together to provide stable operation and long service life.

Optimized Piston Design

The piston is one of the most important parts of a DTH hammer.

The SP480 piston design provides:

High impact strength
Improved wear resistance
Longer service life
Stable impact performance

The optimized stress distribution reduces component fatigue and improves durability during continuous drilling operations.

Low Air Consumption Design

Efficient air usage is essential for reducing drilling costs.

The SP480 DTH Hammer features optimized airflow design to achieve:

Lower compressed air consumption
Improved drilling efficiency
Reduced operating expenses
Better compressor utilization

The model is designed for working pressures around 1.0–1.9 MPa with air consumption of approximately 5.5/9 m³/min.

Wide Application Areas
Mining Industry

The SP480 DTH Hammer is suitable for:

Open pit mining
Blast hole drilling
Mineral extraction preparation
Rock excavation
Quarry Operations

Ideal for:

Marble quarry drilling
Granite extraction
Limestone production
Stone blasting
Water Well Drilling

Used for:

Groundwater exploration
Deep well drilling
Geological investigation
Construction Engineering

Suitable for:

Foundation drilling
Rock anchoring
Infrastructure projects
Advantages Of SP480 DTH Hammer
High Drilling Efficiency

Powerful impact energy improves penetration speed.

Excellent Durability

High-quality materials extend working life.

Stable Performance

Reliable internal structure supports continuous operation.

Lower Operating Cost

Efficient air consumption reduces drilling expenses.

Easy Maintenance

Simple structure allows convenient inspection and servicing.

Wide Compatibility

Suitable for various DTH drilling rigs and drilling applications.

How To Select The Right DTH Hammer

Choosing the correct DTH hammer depends on several factors:

Drill Hole Diameter

The hammer size should match the required hole diameter.

Rock Conditions

Harder rocks require stronger impact performance.

Compressor Capacity

Air pressure and air volume must meet hammer requirements.

Drilling Application

Consider whether the project involves:

Mining
Quarrying
Water wells
Construction drilling

Correct selection improves drilling speed and reduces tool wear.

Why Choose Us
Professional Drilling Equipment Manufacturer

We specialize in DTH hammers, drill bits, drilling rigs, and complete rock drilling solutions.

High Quality Materials

Premium alloy steel and advanced processing technology ensure durability.

Strict Quality Control

Each SP480 DTH Hammer is inspected for:

Dimensional accuracy
Material quality
Performance stability
Assembly reliability
Factory Direct Supply

Competitive manufacturer pricing with consistent product quality.

OEM Customization

Customized solutions are available for:

Hammer specifications
Branding requirements
Drilling conditions
Project needs
Global Export Experience

Our drilling products serve mining, construction, and geological industries worldwide.

Technical Support

We provide:

Product selection assistance
Drilling recommendations
Maintenance guidance
After-sales support
FAQs
1. What is an SP480 DTH Hammer?

The SP480 DTH Hammer is a pneumatic down-the-hole drilling hammer used for rock drilling applications.

2. What industries use SP480 DTH Hammer?

It is mainly used in mining, quarrying, water well drilling, and construction projects.

3. How does a DTH hammer work?

A DTH hammer uses compressed air to drive an internal piston that impacts the drill bit directly.

4. Can the SP480 drill hard rock?

Yes. It is designed for efficient drilling in hard rock formations.

5. What is the working pressure of SP480 DTH Hammer?

The recommended working pressure range is approximately 1.0–1.9 MPa.

6. What air compressor is required?

The required compressor depends on drilling depth, rock condition, and operating pressure.

7. What are the advantages of DTH drilling?

DTH drilling provides high penetration speed, accurate holes, and efficient energy transfer.

8. How can I extend hammer service life?

Regular lubrication, correct air supply, and proper drilling operation can extend service life.

9. Can SP480 DTH Hammer be customized?

Yes. Custom configurations can be provided according to drilling requirements.

10. Do you provide spare parts?

Yes. Spare parts and technical support are available.
