Factory Supply 25HP 30HP 35HP 40HP 45HP 50HP 4WD Wheel Farm Tractor with Loader Technical Parameters

Factory supply 25HP to 50HP 4WD wheel farm tractor with front loader. Ideal for farming, landscaping, material handling, orchard work, and multi-purpose agricultural applications..

Tractor description

25-50hp farm can be used for light ,medium and heavy duty farm work.By using famous diesel engine,reliable gear box,and heavy duty chassis,our tractors has sold to Europe,Australia,South American and Africa ,Asia eg many countries.
tractor also can be equiped with loader,backhoe,wood chipepr,trencher,mower,plough,harrow,trailer,baler eg many implements,can do multy farm work.Tractor specification

The Factory Supply 25HP to 50HP 4WD Wheel Farm Tractor with Front Loader is a versatile and efficient agricultural machine designed for small to medium farms, orchards, landscaping projects, and light construction work. Equipped with a reliable diesel engine and a powerful hydraulic front loader, this tractor provides excellent performance for material handling and field operations.

Its compact structure combined with 4WD traction ensures strong stability, easy maneuverability, and reliable operation in various terrains including muddy fields, orchards, and uneven ground.


SPECIFICATION
Model 254/304 404 504
Drive type 4*4
Engine
Engine brand Laidong or Yangdong Laidong or Yangdong Laidong or Yangdong
Type 3 cylinder, Water-cooling, In-line, 4 stroke 4 cylinder, Water-cooling, In-line, 4 stroke 4 cylinder, Water-cooling, In-line, 4 stroke
Rated speed (r/min) 2300 2300 2300
Engine power (hp) 25hp/30hp/18.4kw/22.1kw 40hp/29.4kw 50hp/36.8kw
Transmission
Clutch Dry, Single or dual type Dry, Single or dual type Dry, Single or dual type
PTO size 6teeth-φ35 6teeth-φ35 6teeth-φ35
PTO Speed(rpm) 540/720 or 540/1000 540/720 or 540/1000 540/720 or 540/1000
Gear shift 8F+2R or 8F+8R 8F+2R or 8F+8R 8F+2R or 8F+8R
Hydraulic system
Hydraulic output valve 2-Way optional 2-Way optional 2-Way optional
Three point linkage
Category of 3-point link Category I Category I Category I
Technical parameter
Dimension(L*W*H) mm 3000*1500*2100 3000*1500*2100 3200*1500*2100
Min. Net weight 1400kg/1450kg 1550kg 1650kg
Wheel base(mm) 1900 1900 1950
Track base(mm) front wheel 1200 1200 1200-1300
Track base(mm) rear wheel 1200 1200 1200-1300
The smallest clearance(mm) 360 360 360
Front tyre 6.0-16/6.5-16 6.0-16/6.5-16 /7.5-16 6.0-16/6.5-16 /7.5-16
Rear tyre 9.5-24/11.2-24 9.5-24/11.2-24/12.4-24 or 11.2-28 9.5-24/11.2-24/12.4-24 or 11.2-28
Steering type Hydraulic power steering Hydraulic power steering Hydraulic power steering
