F460 Horizontal Directional Drilling Rig

rated power：179/2200 KW/R/MIN
maximum torque:1900N-M
maximum pressure：8MPA1.Advanced Hydraulic System: Increases work efficiency by 15%-20% compared to traditional hydraulic systems, reduces system heat generation by 50%, and saves 15%-20% in energy.
2.Track Design: Equipped with steel tracks and optional rubber pads, capable of bearing high loads and operating on various types of terrain.
3.Multi-Function Integrated Dual Handles: Simple operation with high comfort.
4.High-Performance Alloy Steel Gear Rack Push/Pull: High efficiency and smooth operation.
5.Wireless Remote Walking System: Wide field of view, ensuring safety during the walking process.
6.Semi-Automatic Mechanical Arm: Saves time and effort in construction.
7.Standard Drill Rod: φ83 × 3 m; Optional Drill Rod: φ89 × 3 m.

HW460F Horizontal Directional Drill
Machine Configuration	Operating Weight	13000kg
	Engine Brand	Cummins
	Engine Model	B6.7CS4240C
	Engine Power	177KW
	Fuel Tank Capacity	255L
	Main Pump Displacement	256ml/r
	Hydraulic Oil Tank Capacity	255L
	Working Pressure	32Mpa
	Wireless Remote Walking	Standard
	Semi-Automatic Mechanical Arm	Standard
	Cab	Standard
Technical Parameters	Powerhead Push/Pull	Drive Type	Gear Rack Drive
		Maximum Pullback/Push Force	460/460KN
		Maximum Operating Speed of Powerhead	55m/min
	Powerhead Rotation	Drive Type	Dual Motor Drive
		Maximum Rotation Speed	170r/min
		Maximum Torque of Powerhead	19000N·m
	Drill Rod	Standard Rod	φ83*3000mm
		Optional	φ89**3000mm
		Soil Entry Angle	12-24°
	Travel Drive	Drive Type	Rubber tracks
		Travel Speed	5km/3h
	Mud Pump	Maximum Flow	450L/min
		Maximum Pressure	80Bar
		Rotation Diameter	φ200-1200min
		Maximum Construction Distance	650m

F460 Horizontal Directional Drilling Rig

The F460 Horizontal Directional Drilling Rig is an advanced HDD trenchless construction machine designed for efficient underground pipeline and cable installation. It provides a reliable solution for contractors who need to complete underground construction projects while minimizing surface disturbance.

Using modern horizontal directional drilling technology, the F460 HDD Rig creates underground boreholes through a controlled drilling process and installs pipelines, cables, and utility systems without large-scale excavation.

The F460 Horizontal Directional Drilling Rig is designed for projects requiring:

High drilling accuracy
Strong pulling capability
Efficient underground construction
Reduced environmental impact
Flexible operation in complex areas

Compared with traditional excavation methods, the F460 HDD Rig offers significant advantages:

Less damage to roads and landscapes
Reduced construction time
Lower restoration costs
Minimal traffic disruption
Improved project efficiency

The F460 Horizontal Directional Drilling Rig is widely applied in:

Water pipeline installation
Natural gas pipeline projects
Fiber optic cable construction
Underground power cable installation
Municipal infrastructure
Highway crossing projects
River crossing engineering
Industrial pipeline installation

With powerful hydraulic performance and reliable construction design, the F460 provides an efficient trenchless drilling solution for modern underground engineering.

Advanced HDD Trenchless Drilling Technology

The biggest advantage of the F460 Horizontal Directional Drilling Rig is its trenchless construction capability.

Traditional underground installation often requires:

Excavation of large trenches
Road closures
Heavy restoration work
Significant labor input

The F460 HDD Rig uses controlled underground drilling technology to complete installations without extensive surface excavation.

The HDD process includes:

1. Pilot Hole Drilling

The drill head creates an accurate underground path according to the designed route.

2. Hole Reaming

The borehole is enlarged to the required diameter for pipeline installation.

3. Pipe Pullback

The pipeline or cable is pulled through the completed underground passage.

This efficient process makes the F460 ideal for urban and environmentally sensitive construction projects.

Powerful Hydraulic Drilling System

The F460 Horizontal Directional Drilling Rig is equipped with a powerful hydraulic system designed for stable and continuous operation.

The hydraulic system provides:

High rotary torque
Strong push and pull force
Smooth drilling control
Reliable power transmission
Efficient working performance

The hydraulic system controls:

Drill rod rotation
Drill carriage movement
Pullback operation
Steering adjustment
Reaming process

High-quality hydraulic components improve machine reliability and reduce downtime during demanding construction projects.

High Performance Drilling And Pullback Capability

The F460 HDD Drilling Rig is designed for professional underground installation applications.

Its strong drilling performance allows efficient operation in different working conditions.

Key advantages include:

Strong penetration capability
Stable drilling speed
High pulling force
Accurate borehole control
Long-distance underground installation capability

The machine is suitable for installing:

HDPE pipes
Steel pipelines
Electrical cables
Communication cables
Utility conduits
Precise Directional Control System

Accurate underground navigation is essential for successful HDD construction.

The F460 Horizontal Directional Drilling Rig uses advanced steering technology to control:

Drilling direction
Underground depth
Bore path alignment
Entry and exit locations

With proper locating equipment, operators can accurately guide the drill head beneath:

Roads
Highways
Railways
Rivers
Buildings

This precision improves installation success and reduces construction risks.

Wide Application Areas
Water Pipeline Installation

The F460 HDD Rig is widely used for:

Municipal water networks
Industrial water supply systems
Irrigation pipelines

Advantages:

Fast installation
Reduced excavation
Lower restoration requirements
Gas Pipeline Construction

Suitable for:

Natural gas networks
Energy infrastructure
Underground fuel pipelines

The trenchless method helps improve efficiency in populated areas.

Fiber Optic And Communication Projects

Ideal for:

Internet cable installation
Telecom networks
Data communication infrastructure

The F460 allows accurate underground cable placement with minimal surface impact.

Power Cable Installation

Used for:

Underground electrical systems
Renewable energy projects
Utility upgrades
Road And River Crossing Projects

The F460 Horizontal Directional Drilling Rig is suitable for:

Highway crossings
Railway crossings
River crossings
Urban underground construction
Strong Adaptability To Different Ground Conditions

The F460 HDD Rig can be configured for different geological conditions.

Suitable formations include:

Clay
Sand
Soil layers
Gravel
Mixed ground conditions

Different drill bits, mud systems, and drilling tools can be selected according to project requirements.

This flexibility allows contractors to complete various underground construction tasks efficiently.

Durable Heavy-Duty Structure

The F460 Horizontal Directional Drilling Rig is designed for professional construction environments.

Main structural components include:

High-strength steel frame
Heavy-duty drilling carriage
Reliable hydraulic system
Durable drill rod components
Reinforced machine structure

Benefits:

Long service life
Stable performance
Reduced maintenance costs
Improved construction reliability

The robust design allows continuous operation on demanding HDD projects.

Easy Operation And Maintenance

The F460 HDD Rig is designed to provide convenient operation for construction teams.

Features include:

Hydraulic control system
User-friendly operation interface
Easy drilling adjustment
Convenient maintenance points
Efficient troubleshooting

Operator-friendly design helps improve productivity and reduce downtime.

Main Features Of F460 Horizontal Directional Drilling Rig
Advanced trenchless drilling technology
Powerful hydraulic drilling system
High torque rotary capability
Strong push and pull force
Accurate directional control
Efficient underground pipeline installation
Suitable for multiple utility applications
Durable heavy-duty construction
Easy operation and maintenance
Professional HDD drilling performance
Why Choose Our F460 Horizontal Directional Drilling Rig?
1. Advanced Trenchless Technology

Allows underground installation without large-scale excavation.

2. Powerful Hydraulic Performance

Provides strong drilling force and stable operation.

3. High Construction Efficiency

Reduces project time compared with traditional methods.

4. Precise Underground Control

Improves drilling accuracy and installation success.

5. Wide Project Applications

Suitable for pipelines, cables, utilities, and infrastructure projects.

6. Professional Technical Support

We provide customized HDD solutions, spare parts, and after-sales service.

FAQS
1. What is the F460 Horizontal Directional Drilling Rig used for?

The F460 is used for underground pipeline installation, cable laying, and trenchless construction projects.

2. What materials can the F460 install?

It can install HDPE pipes, steel pipes, power cables, fiber optic cables, and communication conduits.

3. What are the advantages of HDD technology?

HDD reduces excavation, protects roads and landscapes, lowers restoration costs, and improves construction efficiency.

4. Can the F460 drill under roads and rivers?

Yes. It is suitable for highway, railway, and river crossing projects.

5. What ground conditions can the F460 handle?

It can work in clay, sand, soil, gravel, and other common geological conditions with proper tooling.

6. How does the operator control drilling direction?

The operator uses a steering system combined with underground locating equipment to guide the drill head.

7. Is the F460 suitable for municipal projects?

Yes. It is widely used for water, gas, communication, and power infrastructure construction.

8. Can the F460 HDD Rig be customized?

Yes. Drilling capacity, tooling, power configuration, and accessories can be customized according to project requirements.

Product Conclusion

The F460 Horizontal Directional Drilling Rig is a powerful, efficient, and reliable HDD machine designed for modern trenchless underground construction.

With advanced directional drilling technology, strong hydraulic performance, precise control, and wide application capability, the F460 helps contractors complete pipeline and cable installation projects faster and more economically.

For companies requiring professional underground drilling equipment, the F460 Horizontal Directional Drilling Rig provides excellent performance, flexibility, and long-term value.
