F135 Horizontal Directional Drilling Rig

Push and pull: kN 135
Maximum speed: m/min 40
Torque: N·m 3200Key Features of the HWF135 Automatic Rod Changing HDD Rig:


1. Automatic Rod Changing System:

   The F135 stands out with its automatic rod changing feature, significantly reducing manual labor and increasing drilling speed. This system

enables smooth transitions between rods, allowing for continuous operation without unnecessary delays, leading to greater efficiency on the job site.


2. Powerful Engine for High-Performance Drilling:

   Equipped with a high-performance engine, the HWF135 delivers strong and consistent drilling power. It can easily handle tough ground conditions,

making it suitable for a wide range of soil types, including rock, clay, and sandy soils.


3. Precise Steering and Control:

   The rig is designed for accurate and precise drilling, ensuring optimal results in horizontal directional drilling projects. Its advanced control system

allows operators to make real-time adjustments for accurate bore paths, minimizing the risk of deviations and ensuring project success.


4. Durable and Rugged Construction:

   Built to withstand the rigors of demanding drilling environments, the HWF135 is constructed from heavy-duty materials that ensure long-lasting

durability. Its rugged build allows it to perform reliably in challenging terrains and under harsh weather conditions, making it a dependable solution for your drilling needs.


5. Compact Design for Versatility:

   Despite its powerful capabilities, the HWF135 boasts a compact and portable design, making it easy to transport and set up in various locations.

This versatility is essential for contractors working in urban, suburban, or rural areas where space may be limited.


6. Cost-Effective and Time-Saving:

   The automatic rod changing system, combined with the rig's high drilling speed, leads to significant time savings on each project. This improved

efficiency translates to lower labor costs and faster project completion, boosting profitability for contractors.


7. Environmentally Friendly:

   The rig is designed with a focus on reducing environmental impact. Its precise drilling capabilities help minimize surface disruption, making it an

ideal solution for projects in environmentally sensitive areas where traditional methods may not be viable.

F135 Horizontal Directional Drilling Rig

The F135 Horizontal Directional Drilling Rig is a compact professional trenchless drilling machine designed for efficient underground installation of pipelines, cables, and utility systems. It provides an economical and practical solution for contractors who require high drilling efficiency while minimizing surface disruption.

Using advanced Horizontal Directional Drilling (HDD) technology, the F135 HDD Rig creates underground bore paths without the need for large-scale excavation. This makes it especially suitable for urban construction, narrow working areas, and projects where protecting existing infrastructure is important.

The F135 Horizontal Directional Drilling Rig is designed for:

Underground pipeline installation
Fiber optic cable construction
Power cable installation
Water supply pipeline projects
Gas pipeline installation
Communication network construction
Municipal underground engineering

Compared with traditional open-cut excavation, the F135 HDD Rig offers:

Less surface damage
Faster construction speed
Lower restoration costs
Reduced environmental impact
Better operation flexibility

The compact structure and efficient hydraulic system make the F135 an excellent choice for small and medium-scale trenchless construction projects.

Advanced Trenchless Drilling Technology

The main advantage of the F135 Horizontal Directional Drilling Rig is its trenchless installation capability.

Traditional underground construction usually requires:

Excavation of long trenches
Road closures
Large construction areas
Expensive surface restoration

The HDD method allows pipelines and cables to be installed underground through controlled drilling.

The F135 HDD construction process includes:

1. Pilot Hole Drilling

The drill head creates a planned underground path with accurate directional control.

2. Hole Enlargement

The borehole is expanded using reaming tools to match the required pipeline diameter.

3. Pipeline Pullback

The pipe or cable is pulled back through the completed underground passage.

This process significantly improves construction efficiency and reduces disruption to surrounding areas.

Compact And Efficient HDD Design

The F135 Horizontal Directional Drilling Rig features a compact structure designed for flexible operation.

Advantages include:

Small working footprint
Easy transportation
Convenient site setup
Excellent maneuverability
Lower operating costs

The compact design makes it suitable for:

City streets
Residential areas
Limited-access construction sites
Utility upgrade projects

Compared with larger HDD machines, the F135 provides greater flexibility for projects requiring mobility and economical operation.

Powerful Hydraulic Drilling System

The F135 HDD Rig is equipped with a reliable hydraulic power system to ensure stable drilling performance.

The hydraulic system provides:

Strong rotary torque
Stable drilling speed
Smooth push and pull operation
Efficient power transmission
Reliable continuous performance

Hydraulic control allows operators to manage:

Drill rod rotation
Forward and backward movement
Steering adjustment
Pullback operations

The optimized hydraulic system improves drilling accuracy and reduces energy consumption.

Precise Directional Control

Accurate underground navigation is essential for HDD projects.

The F135 Horizontal Directional Drilling Rig supports precise control of:

Drilling direction
Underground depth
Borehole route
Entry and exit points

With professional locating equipment, operators can guide the drill head beneath:

Roads
Buildings
Rivers
Railways
Existing infrastructure

This allows safe underground installation with minimal disturbance.

Wide Application Areas
Water Pipeline Installation

The F135 HDD Rig is widely used for:

Municipal water supply systems
Irrigation pipelines
Industrial water networks

Benefits:

Fast installation
Reduced excavation
Lower repair costs
Gas Pipeline Projects

Suitable for:

Natural gas distribution systems
Energy infrastructure
Underground utility construction

The trenchless method improves safety and reduces disruption in populated areas.

Fiber Optic And Communication Cable Installation

Ideal for:

Internet infrastructure
Telecom cable projects
Data network expansion

The F135 enables accurate underground cable placement while protecting roads and landscapes.

Power Cable Installation

Applications include:

Underground electrical systems
Solar power connection lines
Utility modernization projects
Municipal Engineering Projects

Used for:

Urban pipeline upgrades
Underground utility networks
Infrastructure improvements
Excellent Adaptability To Different Working Conditions

The F135 Horizontal Directional Drilling Rig can be used in various ground conditions with suitable drilling tools.

Applicable formations include:

Clay
Sand
Soil layers
Soft gravel
Mixed ground conditions

Different drill heads, reamers, and mud systems can be selected according to project requirements.

This flexibility helps contractors complete different underground installation tasks efficiently.

Durable Construction And Reliable Performance

The F135 HDD Rig is designed for professional construction environments.

Main components include:

High-strength steel frame
Durable drilling carriage
Reliable hydraulic components
Strong drill rod system
Reinforced structural design

Benefits:

Long service life
Stable operation
Reduced maintenance requirements
Improved return on investment

The machine is built to provide dependable performance during continuous construction operations.

Easy Operation And Maintenance

The F135 Horizontal Directional Drilling Rig is designed with operator convenience in mind.

Features include:

Simple hydraulic controls
User-friendly operation system
Easy drilling adjustment
Convenient maintenance points
Reduced training requirements

The practical design improves working efficiency and minimizes downtime.

Main Features Of F135 Horizontal Directional Drilling Rig
Compact HDD drilling machine
Advanced trenchless construction technology
Powerful hydraulic drilling system
Precise directional control
Efficient underground installation capability
Suitable for pipelines and cables
Flexible operation in limited spaces
Durable industrial structure
Low operating cost
Easy maintenance
Why Choose Our F135 Horizontal Directional Drilling Rig?
1. Compact And Flexible Design

Ideal for urban construction and limited working areas.

2. Efficient Trenchless Installation

Reduces excavation work and speeds up underground projects.

3. Reliable Hydraulic Performance

Provides stable drilling power and smooth operation.

4. Accurate Direction Control

Ensures precise underground drilling paths.

5. Wide Application Range

Suitable for water, gas, power, and communication projects.

6. Professional Technical Support

We provide customized solutions, spare parts, and complete after-sales service.

FAQS
1. What is the F135 Horizontal Directional Drilling Rig used for?

The F135 is used for underground pipeline installation, cable laying, and trenchless construction projects.

2. What pipes can the F135 HDD Rig install?

It can install water pipes, gas pipes, HDPE pipes, power cables, and communication cables.

3. What are the advantages of HDD compared with excavation?

HDD reduces surface damage, construction time, traffic interruption, and restoration costs.

4. Is the F135 suitable for urban construction?

Yes. Its compact design makes it ideal for city streets and limited-access areas.

5. Can the F135 drill under roads and buildings?

Yes. It can complete underground crossings with accurate directional control.

6. What soil conditions can the F135 handle?

It can operate in clay, sand, soil, and other common ground conditions with proper tools.

7. Is the F135 easy to operate?

Yes. The hydraulic control system is designed for simple operation and precise adjustment.

8. Can the F135 HDD Rig be customized?

Yes. Drilling tools, machine configurations, and accessories can be customized according to project needs.
