1,The front and rear of machine are powered to rotate, so pipe does not appear to be slipped
and injured when cutting stainless steel round pipe.
2,There is no slenderness ratio 60:1 limit when cutting 6m pipe.
3,The X direction is driven by rack and pinion, the speed is faster than the running speed of the screw.
4,It is double chuck rotation, tube will not lag, and the quality of cut product is good.
The Pipe Laser Cutting Machine is an advanced CNC fiber laser processing system designed for precision cutting of various metal pipes,tubes,and profiles. Using high-performance fiber laser technology,the machine provides fast cutting speed,excellent accuracy,and superior edge quality for modern metal fabrication industries.
Designed for processing round pipes,square tubes,rectangular tubes,and special-shaped profiles,the laser pipe cutting machine integrates cutting,hole drilling,slotting,and contour processing functions into one efficient system. It is widely used in steel structures,metal furniture,automotive components,construction materials,fitness equipment,and industrial machinery manufacturing.
Compared with traditional pipe cutting methods such as sawing,plasma cutting,and mechanical processing,the Pipe Laser Cutting Machine offers higher precision,lower material waste,smoother cutting surfaces,and greater production flexibility. It helps manufacturers improve efficiency,reduce labor costs,and achieve high-quality finished products.
|
Parameters |
|
Power of laser |
1.5kw |
|
Cutting length |
6000mm |
|
Round pipe |
φ3-φ80mm |
|
Square |
60x60mm |
|
Power of laser |
1.5kw |
|
Chuck rotation speed |
150r/min |
|
Positioning accuracy |
±0.05mm |
|
Repeat positioning accuracy |
±0.05mm |
|
Maximum idle speed |
120m/min |
|
Maximum acceleration |
1.0G |
|
Minimum length of tailstock |
≥50mm |
|
Maximum weight of a single tube |
≤50kg |
|
Main machine measure |
2700×1200×1950mm |
|
Measure with feeding frame |
8300x1200x2100mm |
|
Weight |
4200kg |
|
Configuration |
|
Fiber laser cutter |
Osprey |
|
Speed Reducer |
Shinbo Tomokawa Precision |
|
Control Software |
Weihong |
|
Servo motor and driver |
Weihong |
|
Cut off air circuit electrical |
SMC/Air TAC |
|
Water-cooled united |
standard |
Advanced Fiber Laser Pipe Cutting Technology
The Pipe Laser Cutting Machine adopts modern fiber laser technology to achieve high-speed and high-precision metal tube processing.
Main processing functions include:
Pipe cutting
Tube hole cutting
Slot cutting
Profile cutting
Angle cutting
Complex shape cutting
Laser cutting advantages:
High cutting accuracy
Smooth cutting edges
Small heat affected zone
Low material deformation
Reduced secondary processing
The powerful laser beam ensures stable cutting performance for different metal materials and thicknesses.
CNC Intelligent Control System
The machine is equipped with an advanced CNC control system for accurate and convenient operation.
Main functions:
CAD drawing import
Automatic cutting path calculation
Digital parameter setting
Intelligent positioning
Real-time processing monitoring
Benefits:
Easy operation
Fast production changeover
Reduced manual adjustment
Stable cutting quality
Improved production efficiency
The CNC system enables manufacturers to achieve consistent and repeatable tube processing results.
High Precision Pipe Processing Capability
The Pipe Laser Cutting Machine is designed for professional metal tube fabrication.
Suitable materials:
Carbon Steel Pipe
Stainless Steel Tube
Galvanized Steel Pipe
Aluminum Tube
Copper Tube
Alloy Metal Pipe
Suitable profiles:
Round Pipe
Square Tube
Rectangular Tube
Oval Tube
Special Metal Profiles
The machine can meet different industries' requirements for precision tube cutting.
Efficient Laser Tube Cutting Performance
Compared with traditional cutting equipment,the Pipe Laser Cutting Machine provides multiple advantages:
Faster Processing Speed
High-speed laser cutting improves production efficiency and reduces processing time.
Higher Cutting Accuracy
Laser technology ensures precise dimensions and excellent edge quality.
Better Material Utilization
Optimized cutting paths reduce material waste and improve cost efficiency.
Flexible Production Capability
One machine can process different tube shapes and cutting patterns.
Lower Maintenance Cost
Non-contact laser cutting reduces tool wear and replacement costs.
Wide Application Industries
Metal Furniture Manufacturing
Applications:
Chair frames
Table legs
Sofa structures
Decorative metal tubes
Automotive Industry
Used for:
Vehicle frame components
Exhaust pipes
Structural tube parts
Steel Structure Industry
Applications:
Steel frames
Engineering structures
Construction components
Fitness Equipment Manufacturing
Used for:
Exercise equipment frames
Sports equipment structures
Industrial Fabrication
Applications:
Machine frames
Precision tube parts
Custom metal products
Reliable Machine Structure
The Pipe Laser Cutting Machine adopts a heavy-duty industrial design to ensure stable operation.
Main features:
High-strength machine frame
Precision transmission system
Stable tube rotation mechanism
High-quality fiber laser source
Advanced CNC controller
The robust structure provides reliable performance for continuous industrial production.
