The Multi-Station Hydraulic Punching Machine 8/15/20/25/30/50T is a high-efficiency metal processing machine designed for punching,notching,and forming operations on steel tubes,pipes,profiles,and metal sheets. Available in multiple punching force options from 8 Ton,15 Ton,20 Ton,25 Ton,30 Ton to 50 Ton, this machine provides flexible solutions for different industrial production requirements.
Equipped with a multi-station hydraulic structure,the machine allows multiple punching operations to be completed on one platform,significantly improving production efficiency and reducing the need for multiple separate machines. It is widely used in metal furniture manufacturing,steel structure production,automotive components,solar mounting systems,construction materials,and general metal fabrication industries.
Compared with traditional manual drilling and mechanical punching methods,the hydraulic punching machine provides stronger punching force,higher accuracy,better repeatability,and lower labor costs. It is an ideal choice for manufacturers requiring efficient and stable metal tube processing.
1 punct hole, cut notching, press and punch hole
2 fit to carbon steel, stainless steel , copper, aluminum,glass fiber steel and so on
3 hole shape: round, square, rectangle, ellipse, and notch
4 punching type. half(one wall/side), through(two side/wall). 5. Multi-position punching machine can be in accordance with a number of different molds, to achieve a machine with multiple functions, do not have to change the molds frequently, improve production efficiency, easy to use.
Products Description
|
Pressure (ton) |
Max Punching thickness |
Nominal force( |
Power(KW) |
Stroke(mm) |
Model |
|
SS(mm) |
MS(mm) |
|
5 |
1 |
1.2 |
50 |
3 |
70 |
H5A, H5B, H5C, |
|
8 |
1.6 |
2 |
80 |
4 |
100 |
H8A, H8B, H8C, |
|
15 |
2.4 |
3 |
150 |
4 |
120 |
H15A, H15B, H15C,H15D |
|
20 |
4 |
5 |
200 |
5.5 |
150 |
H20A, H20B, H20C,H20D, H20E |
|
25 |
5 |
6 |
250 |
5.5 |
150 |
H20A, H20B, H20C,H20D,
H20E and so on |
Advanced Multi-Station Hydraulic Punching System
The Multi-Station Hydraulic Punching Machine adopts a multi-position working design,allowing different punching operations to be performed efficiently.
The machine can be configured with multiple stations for:
Hole punching
Tube notching
Profile forming
Slot punching
Edge processing
Customized metal forming
The multi-station structure provides:
Faster production speed
Reduced material handling
Improved processing consistency
Higher production capacity
Lower equipment investment
It is especially suitable for factories producing large quantities of standardized metal components.
Multiple Tonnage Options For Different Applications
This hydraulic punching machine is available in various punching force options:
8 Ton Hydraulic Punching Machine
Suitable for:
Thin metal tubes
Small profiles
Light fabrication work
15 Ton Hydraulic Punching Machine
Suitable for:
Steel tubes
Furniture frames
General metal processing
20 Ton Hydraulic Punching Machine
Suitable for:
Medium thickness steel pipes
Industrial components
Structural profiles
25 Ton Hydraulic Punching Machine
Suitable for:
Heavy metal fabrication
Stronger tube materials
30 Ton Hydraulic Punching Machine
Suitable for:
High-strength steel processing
Continuous production
50 Ton Hydraulic Punching Machine
Suitable for:
Heavy-duty industrial punching
Thick metal profiles
Large-scale fabrication
Customers can select suitable punching force according to material thickness,production requirements,and application.
Powerful Hydraulic Punching Performance
The machine uses a high-performance hydraulic system to provide stable and powerful punching force.
Hydraulic system advantages:
Strong punching pressure
Smooth operation
Accurate hole forming
Low vibration
Long service life
It can process various hole types:
Round holes
Square holes
Oblong holes
Mounting holes
Customized holes
The hydraulic punching system ensures reliable operation for continuous industrial production.
Multi-Station Design Improves Efficiency
The multi-station structure allows different processing functions to be integrated into one machine.
Main benefits:
Multiple operations in one setup
Reduced operator movement
Faster production cycle
Improved product consistency
Higher workshop efficiency
This design is suitable for manufacturers who need flexible production capabilities and high output.
Wide Application Industries
The Multi-Station Hydraulic Punching Machine is widely used in:
Metal Furniture Manufacturing
Applications:
Chair frames
Table frames
Bed frames
Storage racks
Office furniture components
Steel Structure Industry
Used for:
Steel brackets
Construction supports
Metal frames
Structural components
Solar Mounting System Production
Suitable for:
Solar brackets
Support rails
Photovoltaic structures
Automotive Industry
Applications:
Vehicle frame components
Metal supports
Tube assemblies
Industrial Fabrication
Used for:
Custom metal parts
Machine components
Metal profiles
Suitable Materials
The hydraulic punching machine can process various materials:
Carbon Steel Tubes
Stainless Steel Pipes
Galvanized Steel Profiles
Aluminum Tubes
Square Tubes
Round Pipes
Rectangular Tubes
Metal Sheets
Different dies and tooling can be customized according to material type and processing requirements.
Easy Operation And Reliable Structure
The machine is designed for convenient operation and long-term industrial use.
Features include:
Simple control system
Quick tooling replacement
Strong machine frame
Stable hydraulic performance
Low maintenance requirements
The robust structure ensures reliable performance in demanding production environments.
Key Features Of Multi-Station Hydraulic Punching Machine
1. Multiple Punching Force Options
Available from 8T to 50T for different production requirements.
2. Multi-Station Processing Design
Allows multiple operations in one machine.
3. Powerful Hydraulic System
Provides stable and efficient punching performance.
4. High Precision Processing
Ensures accurate holes and consistent results.
5. Wide Material Compatibility
Suitable for tubes,pipes,profiles,and metal sheets.
6. Customized Tooling Available
Supports special punching and forming requirements.
Why Choose Our Multi-Station Hydraulic Punching Machine?
Professional Metal Processing Equipment Manufacturer
We specialize in manufacturing hydraulic punching machines and complete metal tube processing solutions for global customers.
Flexible Production Solutions
Different tonnage options and station configurations meet various industrial applications.
High Efficiency And Accuracy
Advanced hydraulic technology ensures stable punching performance and precise processing.
Customized Machine Design
Punching force,number of stations,tooling,and machine configuration can be customized according to customer needs.
Factory Direct Supply
Direct manufacturer supply provides competitive pricing,reliable quality,and professional technical support.
Complete Service Support
We provide installation guidance,operator training,maintenance support,and spare parts supply.
FAQS
Q1: What is a Multi-Station Hydraulic Punching Machine used for?
It is used for punching,notching,and forming metal tubes,pipes,profiles,and sheets.
Q2: What tonnage options are available?
The machine is available in 8T,15T,20T,25T,30T,and 50T models.
Q3: What materials can this machine process?
It can process carbon steel,stainless steel,galvanized steel,aluminum,and other metal materials.
Q4: What are the advantages of multi-station design?
Multi-station design allows multiple operations in one machine,improving efficiency and reducing production time.
Q5: Can different punching dies be installed?
Yes. Customized punching dies and tooling can be provided according to customer requirements.
Q6: Is this machine suitable for mass production?
Yes. The hydraulic system and multi-station structure are designed for continuous industrial production.
Q7: Can the machine be customized?
Yes. Punching force,station quantity,tooling,and automation functions can be customized.
