The Automatic CNC 15 Ton 3M Single Line Square Round Metal Pipe Tube Hole Punching Machine is a high-efficiency CNC metal processing machine designed for automatic punching, stamping, and hole forming on square tubes, round pipes, rectangular tubes, and various metal profiles. Featuring a powerful 15-ton punching system, single-line processing structure, and 3-meter tube processing capability, this machine provides accurate, stable, and economical solutions for modern metal fabrication industries.
Designed for manufacturers requiring high precision and consistent production quality, this CNC pipe hole punching machine is widely used in steel furniture manufacturing, metal fencing, construction components, automotive parts, machinery frames, and decorative metal industries.
Compared with traditional drilling and manual punching methods, the Automatic CNC 15 Ton Tube Hole Punching Machine significantly improves production efficiency by reducing labor requirements, increasing processing accuracy, and ensuring repeatable punching results.
1.Touch Screen settings, CNC control system, precise servo motor positioning, module storage memory function.
2. Structure: Steel plate welded structure
3. Mould replacement: change the dies easily without adjusting the dies to reduce mould damage rate , Skilled workers can change the mould within 10 minutes.
4. Punching Category: (1).single hole punching; (2).double hole punching; (3).Isometric hole punching; (4). none- Isometric hole punching,(5) rotary punching(only for round pipe).(6) punch from upward side and horizontal two sides
5. Hydraulic ,pneumatic and Servo System.
6. Step-less operation adjustment, hydraulic loops designed with zero load, combined with extremely low frequency oil pump motor, effectively reduced noise, increased motor efficiency and service duration.
7. double punching heads machine can punch hole with two hydraulic cylinders, or only one cylinder punch separately. Note: A mean single machine head, B mean double machine heads
The above data is standard configuration, it can be customized in feed length, oil pressure, operation system langue and so on ,also with cutting function or not. Just let us know what you need Products Description
|
Model |
15TA |
15TB |
20TA |
20TB |
|
Feed length |
3000 |
6000 |
3000 |
6000 |
|
Nominal force |
150kn |
250kn |
|
Stroke |
120mm |
150mm |
|
Max punch Thickness |
SS 2.4mm,MS:3mm |
SS 4mm,MS:5mm |
|
Motor power |
5.5kw |
7kw |
|
Punching capacity(metal thickness) |
≤3mm |
≤5mm |
|
Fit to material |
Fiberglass Carbon steel, stainless , copper, aluminum, iron, and so on |
|
Fit to shape |
Round, square, rectangle ,oval, angle steel |
|
Tube and hole size |
Moulds can be customized as different requirement
Depend on tube material and thickness, also hole size, |
|
Punching hole accuracy |
0.01mm |
|
Feed accuracy |
0.1mm |
|
Color |
white , or customized |
|
Feed way |
Slideway and servo motor |
|
Control way |
PLC, 10 inch Touch Screen |
|
Clamping way |
Pneumatic(air compressor is with machine) |
|
programs stored |
200 sets, each program store different processing message |
|
Operation language |
Chinese and English, or customized |
|
Voltage |
220V,380V,415V,440v, customized as requirement |
|
Cutting method(option ) |
Saw blade ,or hydraulic punch cutting |
Measure |
Machine head |
1500x1000x1700mm |
Feed frame |
3500x600x12500mm(single,3m feed)
3500x900x12500mm(double,3m feed)
6500x600x12500mm(single,6m feed)
6500x900x12500mm(double,6m feed) |
High Precision CNC Pipe Hole Punching System
The Automatic CNC 15 Ton 3M Single Line Metal Pipe Punching Machine adopts advanced CNC control technology to achieve accurate positioning and automatic processing.
The machine can perform:
Automatic tube positioning
CNC-controlled hole punching
Continuous production cycles
Accurate hole spacing control
Repeatable batch processing
The CNC system minimizes human error and ensures each workpiece receives consistent punching results, making it suitable for high-volume industrial production.
Powerful 15 Ton Punching Performance
Equipped with a 15-ton stamping force system, this machine provides strong and stable punching capability for different metal tubes and profiles.
The powerful punching system offers:
Smooth punching operation
High processing efficiency
Clean hole edges
Stable pressure output
Long service life
It can handle different tube materials and thicknesses while maintaining excellent processing accuracy.
3 Meter Tube Processing Capability
The 3-meter working length allows manufacturers to process medium-length pipes and tubes efficiently without frequent repositioning.
Advantages include:
Faster production speed
Reduced manual adjustment
Improved processing consistency
Higher output capacity
Better production flexibility
This makes the machine suitable for producing metal frames, furniture structures, railings, and industrial tube components.
Single Line Processing Design
The single-line structure provides a practical and cost-effective solution for factories requiring reliable CNC tube punching operations.
Benefits include:
Simple machine operation
Easy maintenance
Stable punching performance
Lower equipment investment
Suitable for customized production
It is an excellent choice for small and medium-sized manufacturers as well as industrial production lines.
Wide Application Industries
The Automatic CNC 15 Ton 3M Pipe Tube Hole Punching Machine is widely used in:
Steel Furniture Manufacturing
Suitable for processing:
Chair tubes
Table frames
Bed frames
Storage racks
Office furniture structures
Metal Fence And Railing Production
Used for:
Fence pipes
Gate frames
Balcony railings
Decorative metal structures
Construction Industry
Applications include:
Steel supports
Structural components
Metal brackets
Building frames
Automotive And Machinery Manufacturing
Used for:
Equipment frames
Mechanical parts
Tubular components
Vehicle structures
Suitable Materials
The CNC pipe punching machine can process various metal materials:
Carbon Steel Pipe
Stainless Steel Tube
Galvanized Steel Pipe
Iron Tube
Aluminum Profile
Square Tube
Round Tube
Rectangular Tube
Different punching dies can be customized according to tube dimensions, hole shapes, and production requirements.
Advanced CNC Control Technology
The intelligent CNC system improves production accuracy and operational convenience.
Main advantages include:
Programmable punching positions
Automatic positioning control
High repeatability
Easy parameter adjustment
Reduced operator workload
Operators can quickly set processing programs according to different tube specifications.
Efficient Automatic Production
The Automatic CNC 15 Ton Metal Pipe Punching Machine helps manufacturers improve production efficiency by replacing manual drilling and punching operations.
Key benefits include:
Higher Productivity
Automatic operation reduces processing time.
Better Accuracy
CNC positioning ensures precise hole locations.
Lower Labor Costs
Reduces dependence on manual workers.
Improved Product Quality
Maintains consistent punching results.
Safer Operation
Minimizes repetitive manual processing.
Key Features Of Automatic CNC 15 Ton 3M Single Line Pipe Punching Machine
1. CNC Automatic Control
Provides accurate and repeatable punching operations.
2. 15 Ton Strong Punching Force
Suitable for industrial metal tube processing.
3. 3M Tube Processing Length
Handles medium-length pipes and profiles efficiently.
4. Single Line Working Structure
Provides stable performance and easy operation.
5. Square And Round Tube Compatibility
Supports multiple tube shapes and sizes.
6. Customized Punching Dies
Allows different hole designs and patterns.
Why Choose Our Automatic CNC 15 Ton Tube Hole Punching Machine?
Professional CNC Metal Machinery Manufacturer
We specialize in manufacturing CNC punching, stamping, and tube processing equipment for global industrial customers.
High Precision And Reliable Performance
Advanced CNC control, precision tooling, and strong machine structures ensure accurate and stable production.
Customized Solutions
Machine specifications, punching dies, tube sizes, hole patterns, and automation functions can be customized according to customer requirements.
Competitive Factory Direct Supply
Direct manufacturer supply provides competitive prices, reliable quality, and professional technical support.
Complete After-Sales Support
We provide installation guidance, technical training, maintenance service, and spare parts supply.
FAQS
Q1: What is an Automatic CNC 15 Ton 3M Single Line Pipe Punching Machine used for?
It is used for automatic punching and stamping of square tubes, round pipes, and metal profiles.
Q2: What tube shapes can this machine process?
It can process round tubes, square tubes, rectangular tubes, and various hollow metal profiles.
Q3: What is the punching force of the machine?
The machine provides a 15-ton punching force suitable for industrial metal tube processing.
Q4: Can the punching position be programmed?
Yes. The CNC system allows users to set precise punching positions and processing sequences.
Q5: What materials can be punched?
It can process carbon steel, stainless steel, galvanized steel, aluminum, and other metal materials.
Q6: Is this machine suitable for mass production?
Yes. Automatic CNC control makes it suitable for continuous and high-volume production.
Q7: Can different hole shapes be produced?
Yes. Customized punching dies can create different hole shapes according to customer requirements.
