The CE EPA Approved Mini Crawler Skid Steer Loader is a compact, powerful, and versatile machine designed for construction, agriculture, landscaping, property maintenance, and material handling operations. Available in both crawler track and wheel drive configurations, this skid steer loader combines excellent maneuverability, high lifting performance, and multi-function attachment capability.
Equipped with a front bucket and a quick-attach system, the machine can handle loading, digging, transporting, grading, trenching, snow removal, and many other tasks. Its compact design allows operation in confined spaces where larger equipment cannot work efficiently.
|
Engine |
Rato R420/Briggs&Stratton/Koop |
Working three items |
9s |
|
Predetermined power |
13.5hp |
Working system pressure |
17-21bar |
|
Predetermined speed |
3000rpm |
Fuel tank storage |
5L |
|
Number of cylinders |
1 |
Machine weight |
720kg |
|
Intake method |
Natural |
Bucket capacity |
0.06m³ |
|
Displacement |
420cc |
Main pump type/type |
Gear pump/05-05 |
|
Emission standard |
Euro 5-EPA |
Tensioning form |
Mechanical tensioning |
|
Rated load |
200kg |
Dumping height |
1564mm |
|
Maximum load |
300kg |
Dumping distance |
446mm |
|
Maximum digging force |
350kn |
Operating weight |
900kg |
|
Travel speed |
0-6km/h |
Bucket capacity |
0.06m³ |
Certified with CE and EPA compliance, this loader is suitable for export to global markets and meets strict safety and environmental requirements.
|
Engine |
Briggs & Stratton /Koop/Rato |
Rated speed |
3200rmp |
|
Configuration |
Standard dual-way dual valve,
dual-way output |
Turning radius |
1350mm |
|
Hydraulic system pressure |
17mpa |
|
Height |
1400mm |
Load |
330kg |
|
Overall length (including bucket) |
2150mm |
Bucket capacity |
0.15m³ |
|
Length without bucket |
1660mm |
Travel speed |
0-5km/h |
|
Overall length |
960mm |
Hydraulic oil tank capacity |
26L |
|
Wheelbase |
640mm |
Fuel tank capacity |
6.6L |
|
Machine weight |
723kg |
Maximum height |
2375mm |
|
Horsepower |
13.5hp |
Maximum axle pin height |
1875mm |
|
Rated power |
10kw |
Maximum dump height |
1450mm |
|
Engine |
Rato/Briggs&Stratton/Koop |
Rated speed |
3200rmp |
|
Configuration |
Dual-way dual valve, dual-way output |
Turning radius |
1317mm |
|
Optional three pumps and three valves |
Hydraulic system pressure |
17mpa |
|
Height |
1400mm |
Load |
380kg |
|
Total length (including bucket) |
1900mm |
Bucket capacity |
0.17m3 |
|
Length without bucket (without pedal) |
1370 (1350) mm |
Travel speed |
0-5km/h |
|
Overall width |
900mm |
Hydraulic oil tank capacity |
26L |
|
Wheelbase |
640mm |
Fuel tank capacity |
21L |
|
Machine weight |
850kg |
Maximum height |
2300mm |
|
Horsepower |
23hp |
Maximum axle pin height |
1800mm |
|
Rated Power |
15kw |
Maximum dumping height |
1400mm |
Product Advantages
Compact Size
Works efficiently in narrow spaces and restricted job sites.
Multi-Purpose Functionality
Compatible with dozens of skid steer attachments.
Excellent Maneuverability
Zero-turn steering allows precise operation.
High Productivity
Powerful hydraulics and quick attachment changes improve work efficiency.
Low Operating Cost
Fuel-efficient engines and simple maintenance reduce ownership costs.
|
Engine |
Rato/Briggs&Stratton/Koop |
Rated speed |
3200rmp |
|
Configuration |
Dual-way dual valve, dual-way output Optional three pumps and three valves |
Turning radius |
1317mm |
|
Hydraulic system pressure |
17mpa |
|
Height |
1400mm |
Load |
380kg |
|
Total length (including bucket) |
1900mm |
Bucket capacity! |
0.17m³ |
|
Length without bucket (without pedal) |
1370 (1350) mm |
Travel speed |
0-5km/h |
|
Overall width |
900mm |
Hydraulic oil tank capacity |
26L |
|
Wheelbase |
640mm |
Fuel tank capacity |
21L |
|
Machine weight |
850kg |
Maximum height |
2300mm |
|
Horsepower |
23hp |
Maximum axle pin height |
1800mm |
|
Rated Power |
15kw |
Maximum dumping height |
1400mm |
Compact Crawler & Wheel Models Available
Customers can choose between:
Track Skid Steer Loader
Better traction on soft ground
Reduced ground pressure
Excellent slope performance
Suitable for muddy and uneven terrain
Wheel Skid Steer Loader
Faster travel speed
Lower maintenance costs
Ideal for hard surfaces
Flexible operation on construction sites
|
Engine |
Laidong 385/Yanmar 380 |
Departure angle |
23° |
|
Number of cylinders |
3 cylinders |
Rated load |
500kg |
|
Power |
17.8kw |
Vehicle weight |
1330kg |
|
Operating height |
2695mm |
Working system pressure |
250 bar |
|
Height of bucket hinge pin |
2175mm |
Working system flow |
62.4 L/min |
|
Height to top |
1520mm |
Travel system pressure |
250 bar |
|
Overall length with bucket |
2694mm |
Travel system flow display |
62.4 L/min |
|
Overall length without bucket |
2067mm |
Working pressure |
18mpa |
|
Wheelbase |
1080mm |
Gasoline tank capacity |
35L |
|
Overall width |
1070mm |
Travel speed |
6km/h |
|
Minimum ground clearance |
94mm |
|
|
Powerful Hydraulic System
The advanced hydraulic system provides strong lifting force and attachment performance.
Features include:
Fast hydraulic response
High lifting capacity
Smooth operation
Auxiliary hydraulic output
Reliable performance under load
|
Engine |
Laidong 385/Yanmar 380 |
Departure angle |
23° |
|
Number of cylinders |
3 cylinders |
Rated load |
500kg |
|
Power |
17.8kw |
Vehicle weight |
1330kg |
|
Operating height |
2695mm |
Working system pressure |
250 bar |
|
Height of bucket hinge pin |
2175mm |
Working system flow |
62.4 L/min |
|
Height to top |
1520mm |
Travel system pressure |
250 bar |
|
Overall length with bucket |
2694mm |
Travel system flow display |
62.4 L/min |
|
Overall length without bucket |
2067mm |
Working pressure |
18mpa |
|
Wheelbase |
1080mm |
Gasoline tank capacity |
35L |
|
Overall width |
1070mm |
Travel speed |
6km/h |
|
Minimum ground clearance |
94mm |
|
|
