Automatic/Semi-Auto. Pull Type Double-Chuck Laser Tube Cutting Machine Technical Parameters

Automatic/Semi-Auto Pull Type Double-Chuck Laser Tube Cutting Machine delivers high-precision cutting for metal pipes and tubes. Featuring pull type feeding and double chuck positioning,it provides fast,stable,and efficient tube processing solutions..

The Automatic/Semi-Auto Pull Type Double-Chuck Laser Tube Cutting Machine is an advanced CNC fiber laser cutting system designed for efficient and precise processing of metal tubes,pipes,and profiles. Equipped with a pull type feeding structure and double-chuck clamping system,this machine provides excellent stability,high cutting accuracy,and improved production efficiency for modern metal fabrication industries.

This laser tube cutting machine is suitable for processing round tubes,square tubes,rectangular tubes,and various metal profiles. With automatic or semi-automatic operation modes,it offers flexible production solutions for different manufacturing requirements.

Compared with traditional mechanical cutting methods,the fiber laser tube cutting machine provides faster processing speed,smoother cutting edges,higher precision,and lower material waste. It is widely used in metal furniture,automotive components,steel structures,fitness equipment,construction materials,and industrial manufacturing.

Name Specification Origin/Brand
Fiber laser 1000W ultra-fine heart diameter Tottenham Laser
Laser cutting head   Jiaqiang,shanghai
System   Ncstudio
Chuck diameter 90mm
Lead screw C7 precision lead screw
X-axis servo motor 1000W high torque Ncstudio
Y-axis servo motor 1000W high torque Ncstudio
Z-axis servo motor 400W with brake Ncstudio
B-axis servo motor 1500W high torque Ncstudio
Pneumatic electromagnetic valve   AirTAC
Accuracy position accuracy ±0.5mm, hole cutting accuracy ±0.1mm

✅ Ultra-Short Tail Material (50mm): Innovative front clamp avoidance cutting minimizes waste, boosting material utilization and slashing costs !
✅ Professional Pipe Bus System: Advanced control + high-efficiency servo ensures real-time data transmission, zero delay, and precision cutting. Live path display & integrated components for effortless operation.
✅ Blazing Speed: Chuck rotation at 150r/min, idling at 100m/min – faster than ever !


⚙️ Core Configurations
  • Laser Source: MAX/Raike (China)
  • Cutting Head: Osprey (China)
  • Control Software: Bo Chu/Wei Hong Bus System (China)
  • Servo Motors: High-torque bus servo (China)
  • Air Path: SMC/AirTAC (China Taiwan/Japan)
Technical Highlights:
✔ Chuck Speed: Up to 260r/min (adjustable for pipe weight)
✔ Positioning Accuracy: ±0.05mm
✔ Max Idling Speed: 90m/min
✔ Max Acceleration: 2.0G
✔ Host Weight: ~1100kg | Max Single Pipe Weight: ≤50KG


Cutting Capacity:
  • Round Pipe: OD 10-200mm
  • Square/Rectangle Tube: 10x10-200x200mm (Diagonal ≤200mm)
  • Standard Length: 6000mm
Advanced Fiber Laser Tube Cutting Technology

The machine adopts high-performance fiber laser technology to achieve fast and accurate tube processing.

Main processing capabilities include:

Tube cutting
Pipe hole cutting
Slot cutting
Profile cutting
Contour cutting
Customized shape processing

Laser cutting advantages:

High cutting precision
Smooth cutting surface
Minimal heat deformation
Low material waste
No cutting tool replacement

The advanced laser system ensures consistent cutting quality for various metal materials.

Pull Type Feeding System

The pull type feeding structure improves tube processing efficiency and accuracy.

Main features:

Automatic tube pulling
Stable material movement
Reduced manual handling
Improved processing speed
Suitable for continuous production

The pull feeding system ensures accurate tube positioning during the cutting process,especially for long-length materials.

Double Chuck Clamping System

The double chuck structure provides strong and stable tube positioning.

Advantages:

Strong clamping force
Reduced tube vibration
Improved cutting accuracy
Better rotation control
Suitable for long pipes

The dual chuck design allows the machine to maintain stable processing performance during high-speed laser cutting.

Automatic And Semi-Automatic Operation Modes

The machine supports flexible operating modes according to production requirements.

Automatic Mode

Advantages:

Higher production efficiency
Reduced manual operation
Continuous tube processing
Improved productivity
Semi-Automatic Mode

Advantages:

Flexible operation
Lower investment cost
Suitable for customized production
Easy material loading

Users can select the suitable operation mode based on production volume and automation requirements.

CNC Intelligent Control System

The CNC control system provides precise and convenient machine operation.

Main functions:

Automatic cutting path planning
Digital parameter setting
CAD drawing import
Intelligent positioning
Real-time processing monitoring

Benefits:

Easy operation
Faster product switching
Stable cutting performance
Reduced operator requirements
Improved production efficiency
High Precision Metal Tube Processing

The Automatic/Semi-Auto Pull Type Double-Chuck Laser Tube Cutting Machine provides excellent processing quality.

Main advantages:

Accurate dimensions
Smooth cutting edges
Reduced burr formation
Excellent repeatability
Less secondary finishing

The high precision improves downstream processes such as welding,assembly,and fabrication.

Wide Application Industries
Metal Furniture Manufacturing

Applications:

Chair frames
Table structures
Sofa frames
Decorative tubes
Automotive Industry

Used for:

Vehicle frame components
Exhaust systems
Structural tube parts
Fitness Equipment Manufacturing

Applications:

Exercise equipment frames
Sports structures
Metal supports
Construction Industry

Used for:

Steel structures
Railings
Architectural components
Industrial Fabrication

Applications:

Machine frames
Precision metal parts
Custom tube products
Suitable Materials

The machine can process various metal materials:

Carbon Steel
Stainless Steel
Aluminum
Copper
Brass
Alloy Steel

Suitable profiles:

Round Tubes
Square Tubes
Rectangular Tubes
Oval Tubes
Special Metal Profiles

Different laser power configurations can be selected according to material thickness and production requirements.

Advantages Compared With Traditional Tube Cutting
Higher Processing Accuracy

Fiber laser technology provides precise cutting dimensions and excellent edge quality.

Faster Production Speed

High-speed laser cutting improves manufacturing efficiency.

Better Material Utilization

Optimized cutting paths reduce material waste.

Flexible Processing Capability

One machine can handle multiple tube shapes and cutting designs.

Lower Maintenance Cost

Non-contact cutting reduces tool wear and replacement expenses.
