DXL-3.5T Single Drum Road Roller

PARAMETERS

Model	DXL-3.5T
Working weight (kg)	3500
Exciting force (Kn)	45
Engine model	Changchai Water Cooled 390
Engine power (kw)	28.5
Static line load (N/cm)	57
Walking speed (km/h)	1.95-7.15
Amplitude (mm)	0.6
Vibration mode	Hydraulicsteering,hydraulicvibration,mechanicaldrive
Gradeability (%)	30
Walking style	Rear wheel drive
Vibration frequency (Hz)	70
Start method	Electric start
Dimensions (mm)	3500*1390*2200
Water tank volume (L)	30
Steel wheel size (mm)	φ1000*1200
Hydraulic oil tank volume (L)	60
Drive method	Full hydraulic drive

In the development of the new 3.5T road roller, we have placed special emphasis on enhancing the edge blanking procedure. This advancement eliminates the requirement of using a smaller road roller for the edge banding and compaction process. For starting the machine, you have the option to choose between manual start and electric start. While manual start is recommended, electric start is recommended in colder temperature conditions.
DXL-3.5T Single Drum Road Roller
Powerful Hydraulic Vibratory Roller For Soil And Road Compaction

The DXL-3.5T Single Drum Road Roller is engineered for contractors, construction companies, municipalities, and rental businesses that require reliable compaction performance in a compact and efficient machine.

Designed with a heavy-duty vibrating steel drum, hydraulic drive system, reinforced frame structure, and powerful diesel engine, the DXL-3.5T delivers consistent compaction results across different construction materials including soil, gravel, sand, crushed stone, and asphalt.

A high-quality road foundation depends on proper compaction. Insufficient compaction can lead to settlement, cracks, uneven surfaces, and reduced service life. The DXL-3.5T helps operators achieve higher material density and improved stability through strong vibration technology and optimized drum pressure.

Unlike double drum rollers that are mainly focused on surface finishing, single drum rollers are especially effective for soil compaction, earthwork preparation, and foundation construction. The large vibrating drum transfers energy deeply into the material layer, making it suitable for road bases, construction sites, and heavy-duty preparation work.

The hydraulic drive system provides smooth forward and reverse movement, precise speed control, and excellent operating comfort. Its compact structure allows efficient operation in areas where larger rollers may not be practical.

With durable components, strong vibration performance, and easy maintenance, the DXL-3.5T Single Drum Road Roller is an ideal solution for professional users seeking dependable and cost-effective compaction equipment.

Key Features Of DXL-3.5T Single Drum Road Roller
Heavy-Duty Single Vibrating Drum

The reinforced steel drum provides powerful compaction force and excellent durability for continuous operation on soil, gravel, and foundation materials.

Strong Vibration Performance

The advanced vibration system generates high centrifugal force to improve material density and reduce the number of passes required. Comparable 3.5-ton models commonly provide 45–53 kN excitation force.

Hydraulic Drive System

The hydraulic transmission system ensures smooth operation, accurate control, and reliable performance under different working conditions.

Powerful Diesel Engine

The efficient diesel engine provides stable power output, low fuel consumption, and long service life.

Excellent Soil Compaction Capability

The single drum design is especially suitable for compacting soil, gravel, sand, aggregate, and foundation layers.

Strong Gradeability

The machine provides excellent climbing ability for uneven terrain, slopes, and challenging construction environments.

Durable Steel Frame

The reinforced chassis structure improves machine stability and supports long-term heavy-duty operation.

Comfortable Operator Platform

Ergonomic controls and an operator-friendly layout improve working efficiency and reduce fatigue.

Compact Working Radius

The optimized design allows operation in relatively narrow construction areas and restricted job sites.

Easy Maintenance

Convenient access to service components reduces downtime and simplifies routine maintenance.

Applications Of DXL-3.5T Single Drum Road Roller
Road Construction

Ideal for compacting road bases, subgrades, gravel layers, and foundation materials.

Highway And Rural Road Projects

Suitable for soil stabilization, road expansion, and infrastructure development.

Municipal Engineering

Used for city roads, sidewalks, parks, drainage projects, and public construction.

Foundation Preparation

Provides reliable compaction for buildings, warehouses, industrial facilities, and commercial projects.

Landscaping Projects

Compacts soil, gravel, and earth surfaces for parks, gardens, and outdoor developments.

Parking Lot Construction

Suitable for base preparation before asphalt or concrete paving.

Utility Installation

Used for compacting backfill after underground pipeline, cable, and drainage installation.

Industrial Construction

Supports factory sites, logistics areas, and large-scale construction projects.

Advantages Of DXL-3.5T Single Drum Road Roller
Deep Compaction Performance

The vibrating steel drum transfers energy effectively into deeper material layers.

Higher Construction Efficiency

Strong vibration reduces working time and improves project productivity.

Excellent Stability

The balanced structure provides reliable operation on different surfaces.

Versatile Working Capability

Suitable for soil, gravel, asphalt, sand, and aggregate materials.

Lower Operating Costs

Durable components and efficient fuel consumption reduce maintenance expenses.

Easy Transportation

Compact dimensions make transportation between job sites more convenient.

Long Service Life

Heavy-duty construction ensures reliable performance in demanding environments.

Designed For Professional Construction Projects

The DXL-3.5T Single Drum Road Roller is built for users who need more than basic compaction equipment. It combines strong working capability, efficient operation, and dependable durability to meet the needs of modern construction projects.

From road foundations and earthwork preparation to industrial sites and municipal infrastructure, this roller provides consistent performance in demanding conditions.

The powerful vibration system improves soil density and foundation stability, helping create stronger and longer-lasting construction results. The hydraulic drive system allows operators to control the machine smoothly, while the durable drum and frame structure ensure reliable operation over extended periods.

Whether used by contractors, rental companies, government projects, or infrastructure developers, the DXL-3.5T provides an economical and professional compaction solution.

Reliable Single Drum Roller Solution

The DXL-3.5T Single Drum Road Roller delivers the ideal combination of power, efficiency, and flexibility.

Its strong compaction ability makes it suitable for demanding earthwork applications, while its compact design allows easy transportation and operation.

For road construction, foundation preparation, landscaping, and municipal engineering, the DXL-3.5T helps contractors complete projects faster while maintaining excellent construction quality.

Why Choose Us
Professional Construction Machinery Manufacturer

We specialize in manufacturing road rollers, crawler dumpers, compactors, excavators, and other construction machinery.

Strict Quality Control

Every machine is carefully inspected and tested before shipment.

Advanced Manufacturing Technology

Modern production facilities ensure precise engineering and consistent quality.

Competitive Factory Pricing

Direct factory supply provides high-quality equipment at competitive prices.

OEM And Customization Service

We support customized colors, logos, engine brands, and machine configurations.

Fast Production And Delivery

Efficient manufacturing ensures timely worldwide shipment.

Global Export Experience

Our construction machinery is exported to North America, Europe, South America, Africa, Southeast Asia, and the Middle East.

Professional After-Sales Support

We provide spare parts, technical guidance, maintenance support, and warranty service.

FAQs
1. What is the DXL-3.5T Single Drum Road Roller used for?

It is mainly used for compacting soil, gravel, sand, asphalt, and foundation materials in construction projects.

2. What is the advantage of a single drum roller?

Single drum rollers provide deeper compaction and are especially effective for soil and earthwork applications.

3. Is the DXL-3.5T suitable for road construction?

Yes. It is widely used for road bases, rural roads, highways, and infrastructure projects.

4. Can it compact gravel and crushed stone?

Yes. The vibration system provides excellent results on gravel, aggregate, and crushed stone surfaces.

5. Does it use hydraulic drive?

Yes. The hydraulic system provides smooth movement and precise operation control.

6. Is it suitable for asphalt compaction?

Yes, especially for base layers and preparation work before final asphalt finishing.

7. What industries use this machine?

Construction companies, road contractors, municipalities, landscaping companies, and rental businesses.

8. Is maintenance difficult?

No. The machine is designed with simple maintenance procedures and accessible service points.

9. Can customized options be provided?

Yes. Engine brands, colors, logos, and optional configurations can be customized.

10. Do you provide spare parts and technical support?

Yes. We provide worldwide spare parts supply, technical support, and after-sales service.
